DANFOSS 132F0002 Variable Frequency Drive (VFD)

Send Inquiry

Request To Call Back

DANFOSS 132F0002 Variable Frequency Drive (VFD)

Name: DANFOSS 132F0002 Variable Frequency Drive (VFD)
Brand: Industrial Online Services
Price: 20000 INR
Availability: InStock

Price 20000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

DANFOSS 132F0002 Variable Frequency Drive (VFD) Specification

Working Temperature
-10C to +50C

Current Range
0 to 2.2 A

Connector Type
Screw Terminal

Output Type
Three Phase AC

Power Supply
200-240V AC 1-phase

Output Current
2.2 A

Noise Level
< 70 dB

Application
Industrial Automation, Pump, Fan, Conveyor, HVAC

Phase
Single Phase Input / Three Phase Output

Rated Current
2.2 A

Rated Power
0.37 kW

Power Factor
>0.98

Features
Compact size, Integrated keypad, Easy set up, Digital display, Integrated EMC filter

Cooling Method
Natural Air Cooled

Operating Temperature
-10C to +50C

Product Type
Variable Frequency Drive (VFD)

Output Power
0.37 kW (0.5 HP)

Output Frequency
0 - 400 Hz

Input Voltage
200-240V AC

Voltage Protection
Overvoltage, Undervoltage

Efficiency
Typically >95%

Material
Industrial Grade Plastic & Metal

Line Regulation
0.3%

Storage Temperature
-25C to +65C

Weight
0.6 kg (approx.)

Ambient Humidity
Max. 95% RH (non-condensing)

Model Number
132F0002

Enclosure Rating
IP20

Protection Features
Overcurrent, Overload, Short circuit, Overtemperature, Ground fault

Control Method
V/Hz (Volts per Hertz)

Communication Interface
Optional (RS485/Modbus via expansion module)

Start-Up Torque
150% at 1 Hz

Mounting Type
Panel Mount

Display
LED digital display

DANFOSS 132F0002 Variable Frequency Drive (VFD) Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
5-7 Days

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About DANFOSS 132F0002 Variable Frequency Drive (VFD)

DANFOSS 132F0002 Variable Frequency Drive VFD

Core Specifications

Typecode FC051PK37S2E20H3XXCXXXSXXX

Power Rating 037 kW 050 HP

Input Voltage Singlephase 200 240 V AC 5060 Hz

Output Current 22 A

Enclosure Rating IP20 Chassis requires panel mounting

RFI Filter Class A1B C1 builtin for radio frequency interference reduction

Brake Chopper Not included no dynamic braking support

Control Panel LCP Not included by default the display panel like LCP 11 or LCP 12 must be purchased separately

Technical Features

Coated PCBs Protects electronic components against dust moisture and corrosion

High Torque Delivers up to 150 of rated motor torque for up to 1 minute

Builtin Protection Features integrated protection against earth faults overtemperature and shortcircuits

Communication Pluggable RS485 port supporting standard Modbus RTU and FC Protocols

IO Interface 5 programmable digital inputs 1 analog input and 1 analog output

Advanced Speed Control for Industrial Efficiency

The DANFOSS 132F0002 VFD deploys advanced V/Hz control technology to regulate motor speed and torque with accuracy. It accommodates dynamic automation needs, handling fluctuations in demand while safeguarding equipment with overcurrent, overload, and ground fault protection. The drive's output frequency range of 0 to 400 Hz enhances application flexibility.

User-Friendly Design and Compact Build

Featuring a compact panel-mountable design, this VFD fits seamlessly into modern control panels. Its integrated keypad and LED digital display streamline setup and daily operation, providing at-a-glance monitoring. Natural air cooling and integrated EMC filtering further reduce maintenance needs and electrical interference.

Robust & Reliable Performance in Demanding Environments

Designed with industrial-grade materials, the DANFOSS 132F0002 excels in settings with high ambient humidity (up to 95% RH) and temperatures ranging from -10C to +50C. Overvoltage and undervoltage protection, combined with a high efficiency (>95%) and power factor (>0.98), make it an energy-efficient choice for critical operations.

FAQ's of DANFOSS 132F0002 Variable Frequency Drive (VFD):

Q: How do I set up the DANFOSS 132F0002 VFD for the first time?

A: Setting up the DANFOSS 132F0002 involves secure panel mounting, wiring the input (200-240V AC, single phase) and the three-phase output connections, and configuring parameters through the integrated keypad and LED digital display. The user manual provides step-by-step procedures for safe and reliable installation.

Q: What protection features does this VFD offer to ensure equipment safety?

A: This model includes numerous protection features such as overcurrent, overload, short circuit, overtemperature, ground fault, overvoltage, and undervoltage. These ensure your connected equipment remains protected from common electrical faults, minimizing downtime and damage risks.

Q: When should I consider using the optional RS485/Modbus communication interface?

A: The optional RS485/Modbus interface is recommended when you need remote monitoring, parameter adjustment, or integration with building management or industrial automation systems. It is especially useful in larger setups where centralized control is a priority.

Q: Where can the DANFOSS 132F0002 VFD be used?

A: This drive is suitable for industrial automation applications, including pumps, fans, conveyors, and HVAC systems. Its compact IP20-rated enclosure and robust engineering make it ideal for panel mounting in various manufacturing and process environments.

Q: What are the benefits of the integrated EMC filter and natural air cooling?

A: The integrated EMC filter minimizes electromagnetic interference with nearby equipment, supporting compliance with industrial standards. Natural air cooling reduces maintenance requirements and eliminates the need for additional cooling fans, ensuring reliable, quiet operation.

Q: How much torque does the VFD provide at low speeds?

A: The DANFOSS 132F0002 delivers up to 150% of full torque at just 1 Hz, which is particularly beneficial for applications like conveyors and pumps that require strong starting performance or low-speed operation without stalling.
