ESA VT505W00000 5.7-inch Widescreen TFT LCD Human-Machine Interface (HMI) Operator Terminal

Send Inquiry

Request To Call Back

ESA VT505W00000 5.7-inch Widescreen TFT LCD Human-Machine Interface (HMI) Operator Terminal

Name: ESA VT505W00000 5.7-inch Widescreen TFT LCD Human-Machine Interface (HMI) Operator Terminal
Brand: Industrial Online Services
Price: 15000 INR
Availability: InStock

Price 15000 INR/ Number

Get a Price/Quote

MOQ : 1 Piece

ESA VT505W00000 5.7-inch Widescreen TFT LCD Human-Machine Interface (HMI) Operator Terminal Specification

Frequency
Not specified (DC powered)

Operating Temperature
0C to 50C

Rated Voltage
24V DC

Input Current
Max. 0.45 A at 24V DC

Humidity
10% to 90% RH (non-condensing)

Phase
Single phase (DC application)

Protection Level
IP65 (front panel, when properly installed)

Mounting Type
Panel Mount

Main Material
Plastic and glass (front panel), metal housing

Processing Type
Digital processing via microcontroller

Condition
Used/Good condition

Function
Human-Machine Interface (HMI) Operator Terminal

Application
Industrial automation; machine control interface

Dimension (L*W*H)
Approx. 182 mm 142 mm 36 mm

Power Mode
Direct Current (DC)

Voltage
24V DC

Power Consumption
Approx. 11 W

Battery Life
Not applicable (mains powered)

Accessories
None supplied

Backlight
LED, replaceable

Model Number
VT505W00000

Weight
Approx. 1.2 kg

Storage
Internal flash memory for program/user data

Display Resolution
320 x 240 pixels (QVGA)

Software Compatibility
ESA POLYMATH software suite

User Memory
Approx. 16 MB (user application)

Touch Panel
Analog resistive touchscreen

Communication Ports
RS232/RS422/RS485 serial ports, 1 x USB (device/host), Ethernet (model dependent)

Graphic Capability
Supports bitmap/graphic objects, trend graphs, alarm table

Display Type
5.7-inch Widescreen TFT LCD

Display Colors
65,536 colors (16-bit)

ESA VT505W00000 5.7-inch Widescreen TFT LCD Human-Machine Interface (HMI) Operator Terminal Trade Information

Minimum Order Quantity
1 Piece

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About ESA VT505W00000 5.7-inch Widescreen TFT LCD Human-Machine Interface (HMI) Operator Terminal

ESAVT505W00000 57inch Widescreen TFT LCD HumanMachine Interface HMI Operator Terminal

Technical Specifications

Display Size 57inch widescreen

Display Type TFT LCD touch screen 800x480 pixels

Operating Voltage 24V DC nominal input range 1832V DC

Power Consumption 10W

Protection Class IP65 front panel protection against dust and water

Operating System Windows CE embedded

Enclosure Type 1 Type 12 aluminum and polycarbonate housing

Mounting Vertical panel mount

Certifications ATEX Zone 222 category 3 GD Eex Na Ii T4 X CE and UL

Versatile Touchscreen Display

The VT505W00000 features a vivid 5.7-inch widescreen TFT LCD with analog resistive touchscreen technology. Supporting up to 65,536 colors and a QVGA resolution, the terminal delivers clear and responsive interaction, making data entry and monitoring straightforward for operators in industrial settings.

Reliable Industrial Connectivity

Equipped with RS232, RS422, RS485 serial interfaces, USB (device/host), and optional Ethernet (model dependent), this HMI terminal excels in seamless communication with various industrial devices. Its compatibility with different networks allows for easy integration into both new and existing automation systems.

Robust Design for Harsh Environments

Built for the rigors of industrial applications, the VT505W00000's panel-mountable IP65-rated front panel provides optimal protection against dust and water ingress. With an operating temperature range from 0C to 50C and humidity tolerance up to 90% non-condensing, it remains reliable in challenging environments.

FAQ's of ESA VT505W00000 5.7-inch Widescreen TFT LCD Human-Machine Interface (HMI) Operator Terminal:

Q: How is the ESA VT505W00000 HMI Operator Terminal installed?

A: The VT505W00000 is designed for panel mounting. Proper installation ensures its IP65 front panel rating, which protects against dust and water when mounted in a compatible enclosure.

Q: What are the main benefits of using this HMI device in industrial automation?

A: Operators benefit from intuitive controls, a highly visible widescreen display, and adaptable communication options, all combining to streamline machine control, enhance monitoring, and support efficient troubleshooting.

Q: When should the backlight be replaced in the VT505W00000?

A: The backlight is LED-based and designed for long life, but if the screen becomes dim, the backlight may be replaced as necessary to maintain optimal visibility.

Q: Where can the VT505W00000 be used effectively?

A: This HMI terminal is ideal for industrial environments such as manufacturing plants, automation control panels, and machine interfaces, where robust operation and easy integration are essential.

Q: How does the user interface process data and display information?

A: The unit employs digital processing via a microcontroller, allowing it to render graphics, handle trend graphs, and manage alarm tables, all accessible through its analog resistive touchscreen.

Q: What is needed to program or set up this HMI terminal?

A: Configuration and programming are performed using the ESA POLYMATH software suite, which enables users to design interfaces, manage applications, and configure device parameters efficiently.

Q: What are the power requirements and consumption details for this HMI?

A: The VT505W00000 operates on a 24V DC input, drawing a maximum of 0.45 A, and consumes approximately 11 W, making it energy efficient for continuous industrial use.
