PHILIPS DDBC300-DALI DIN-Rail Mountable Lighting Controller Designed For Cost-Effective Control Of DALI High-Frequency Fluorescent Ballast And LED Drivers

Send Inquiry

Request To Call Back

PHILIPS DDBC300-DALI DIN-Rail Mountable Lighting Controller Designed For Cost-Effective Control Of DALI High-Frequency Fluorescent Ballast And LED Drivers

Name: PHILIPS DDBC300-DALI DIN-Rail Mountable Lighting Controller Designed For Cost-Effective Control Of DALI High-Frequency Fluorescent Ballast And LED Drivers
Brand: Industrial Online Services
Price: 15000 INR
Availability: InStock

Price 15000 INR/ Number

Get a Price/Quote

MOQ : 1 Piece

PHILIPS DDBC300-DALI DIN-Rail Mountable Lighting Controller Designed For Cost-Effective Control Of DALI High-Frequency Fluorescent Ballast And LED Drivers Specification

Protection Level
IP20

Frequency
50/60 Hz

Humidity
0% to 90% non-condensing

Mounting Type
DIN Rail Mountable

Phase
Single Phase

Input Current
<25mA

Output Voltage
as per DALI standards

Operating Temperature
0C to +40C

Efficiency
High (optimized for low power loss)

Rated Voltage
230V AC

Main Material
PC/ABS Housing

Processing Type
Electronic Control Module

Condition
New

Function
Lighting Automation, DALI Bus Control, Scene Setting, Group Control

Application
DALI high-frequency fluorescent ballasts, DALI LED drivers, Commercial lighting control

Dimension (L*W*H)
157 mm x 88 mm x 60 mm

Power Mode
Mains Powered

Voltage
230V AC

Power Consumption
Max 4W

Accessories
DIN Rail Mounting kit included

Enclosure
IP20 rated, flame-retardant plastic

DALI Bus Output
Up to 300 mA (sufficient for up to 192 DALI ballasts/devices)

Reset Function
Yes (via button)

Color
Black/Grey

Status Indication
LED indicators for Power, DALI activity, and Network

Communication
DALI interface, RS485 for network

Control Protocol
DALI (Digital Addressable Lighting Interface)

Network Type
Philips Dynet

Model
DDBC300-DALI

Firmware Updates
Upgradable via software

Type
DIN-Rail Mountable DALI Controller

Storage Temperature
-25C to +70C

Weight
Approx. 450g

PHILIPS DDBC300-DALI DIN-Rail Mountable Lighting Controller Designed For Cost-Effective Control Of DALI High-Frequency Fluorescent Ballast And LED Drivers Trade Information

Minimum Order Quantity
1 Piece

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About PHILIPS DDBC300-DALI DIN-Rail Mountable Lighting Controller Designed For Cost-Effective Control Of DALI High-Frequency Fluorescent Ballast And LED Drivers

PHILIPS DDBC300DALI DINRail Mountable Lighting Controller Designed For CostEffective Control Of DALI HighFrequency Fluorescent Ballast And LED Drivers

Key Specifications

Power Supply 100240V AC 5060Hz Single Phase 05A input

Control Outputs 3 independent DALI universes

Capacity 192 DALI channels total 64 per universe

Protocol Integrates DALI directly into the Philips DyNet network protocol

Internal Bus Power Features an integral DALI bus power supply eliminating the need for external network power injectors

Form Factor Standard DINrail mountable for clean distribution board installation

Key Benefits Diagnostics

Scalability Direct mapping to the DyNet protocol seamlessly bypasses native DALI network restrictions such as maximum group size limitations

Builtin Diagnostics Tracks driver runtime monitors onlineoffline status and reports lamp or driver failures directly over the network

Device Compatibility Works outofthebox with standard DALI electronic transformers highfrequency fluorescent ballast components and DALI LED fixtures

Seamless DALI Integration

Designed for compatibility with high-frequency fluorescent ballasts and DALI LED drivers, the PHILIPS DDBC300-DALI allows centralized control for expansive lighting setups. Its DIN-rail mount format ensures streamlined installation in commercial environments where reliability and scalability are essential.

Efficient and Safe Operation

With a rugged IP20 flame-retardant housing and reliable operation between 0C and +40C, this controller ensures long-lasting performance. LED indicators provide quick power, network, and DALI activity status, while firmware updates and a physical reset function offer effortless maintenance.

FAQ's of PHILIPS DDBC300-DALI DIN-Rail Mountable Lighting Controller Designed For Cost-Effective Control Of DALI High-Frequency Fluorescent Ballast And LED Drivers:

Q: How does the PHILIPS DDBC300-DALI Lighting Controller connect to a lighting system?

A: The controller connects using the DALI interface for lighting control and utilizes RS485 for network communication within a Philips Dynet system, allowing for seamless integration with compatible fixtures and devices.

Q: What is the maximum number of DALI devices the DDBC300-DALI can support?

A: This controller can manage up to 192 DALI ballasts or LED drivers, thanks to its output capacity of up to 300 mA on the DALI bus.

Q: When should I use the reset function on the DDBC300-DALI controller?

A: The reset function, accessible via a button on the controller, is typically used during troubleshooting or after configuration changes to ensure proper operation.

Q: Where is the PHILIPS DDBC300-DALI ideally installed?

A: The controller is DIN-rail mountable, making it suitable for installation in electrical cabinets or commercial switchboards within commercial lighting environments.

Q: What is the process for updating the firmware on this lighting controller?

A: Firmware updates can be performed via software, ensuring that your controller remains up-to-date with the latest features and improvements without needing to replace hardware.

Q: How does this controller benefit commercial lighting automation?

A: It enables centralized, programmable automation with features like scene setting and group control, optimizing energy efficiency and allowing flexible, scalable lighting management across large installations.
