Vigor VB2-32MP-D Compact Programmable Logic Controller

Send Inquiry

Request To Call Back

Vigor VB2-32MP-D Compact Programmable Logic Controller

Name: Vigor VB2-32MP-D Compact Programmable Logic Controller
Brand: Industrial Online Services
Price: 25000 INR
Availability: InStock

Price 25000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Vigor VB2-32MP-D Compact Programmable Logic Controller Specification

Input Current
-

Efficiency
-

Rated Voltage
24V DC

Operating Temperature
0C to 55C

Mounting Type
DIN Rail Mount or Panel Mount

Frequency
50/60 Hz

Output Voltage
Relay/Transistor Output (typically 24V DC relay or external relay)

Phase
Single

Protection Level
IP20 (approximate, as typical for such PLC)

Humidity
5-95% RH (Non-condensing)

Main Material
ABS Plastic and Electronic Components

Processing Type
Programmable Logic Controller

Condition
Used

Function
PLC Automation Controller

Application
Industrial Automation, Machine Control

Dimension (L*W*H)
110 x 90 x 40 mm (approx)

Power Mode
DC Powered

Voltage
24V DC

Power Consumption
Approx. 7W

Accessories
Not Included

Output Type
Relay or Transistor (model-dependent, VB2-32MP-D usually relay)

Input Points
16 Digital Inputs

PLC Type
Compact Modular

Output Points
16 Digital Outputs

Weight
Approx. 350g

Expansion Capability
Supported via Expansion Modules

Model Number
VB2-32MP-D

Compliance
CE, RoHS (if specified by manufacturer)

Indicator LEDs
Yes (Input/Output status)

Programming Method
Ladder Logic

Communication Port
RS232 (onboard, expansion possible)

Memory Capacity
4K Steps (approx.)

Vigor VB2-32MP-D Compact Programmable Logic Controller Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

Vigor VB2-32MP-D Compact Programmable Logic Controller About

Vigor VB2-32MP-D Compact Programmable Logic Controller

The VB2-32MP-D is a compact Programmable Logic Controller (PLC) main unit manufactured by Vigor Electric Corp.. It is primarily designed for high-speed switching and reliable automation control in diverse industrial environments.

Technical Specifications

Total I/O Points: 32 Points (consisting of 16 Digital Inputs and 16 Digital Outputs).
Input Type: 24V DC signal inputs.
Output Type: PNP Transistor outputs, making it ideal for high-speed, repetitive switching tasks.
Power Supply: 24 VDC operational voltage.
High-Speed Functionality: Includes 8 high-speed input points and 4 high-speed output points for precision timing.
Memory Capacity: 64K steps utilizing a built-in Flash ROM, meaning a battery backup is not required to retain data.
Communication Ports: Built-in USB and RS-485 physical ports supporting standard MODBUS protocols.
Physical Construction: Built with durable, insulated ABS plastic and metal with an IP20 ingress protection rating and integrated overheating protection.
Wiring Connection: Employs reliable barrier screw terminal blocks for secure hardware interfacing

Versatile Automation Control

The Vigor VB2-32MP-D PLC offers robust automation performance with its 32 configurable I/O points, supporting a wide range of industrial and machine control tasks. Its relay-based outputs (model-dependent) provide compatibility with various external devices, ensuring adaptability for diverse automation requirements.

Expandable and Easy to Integrate

Expansion through additional modules allows users to scale up as operational demands grow. With DIN rail or panel mounting options and compact dimensions, the VB2-32MP-D fits easily into control panels, maximizing space and simplifying installation within both new and existing systems.

Efficient Programming and Communication

Ladder logic programming offers intuitive setup and maintenance, making the PLC suitable for both experienced engineers and technicians. Its built-in RS232 port, with optional expansion, enables seamless communication with other control systems or devices, improving connectivity and system integration.

FAQ's of Vigor VB2-32MP-D Compact Programmable Logic Controller:

Q: How do I program the Vigor VB2-32MP-D PLC for industrial automation tasks?

A: Programming the VB2-32MP-D is accomplished using ladder logic, which is an industry-standard method familiar to most automation professionals. You can program the device via compatible software on a connected PC, utilizing the built-in RS232 communication port for data transfer.

Q: What applications benefit most from using the Vigor VB2-32MP-D?

A: The VB2-32MP-D is ideal for controlling industrial processes and machinery, such as conveyor systems, packaging machines, and automated assembly lines. Its combination of digital inputs/outputs and expansion capability makes it suitable for various manufacturing and automation environments.

Q: When should I consider expanding the I/O capability of the VB2-32MP-D?

A: You should expand the I/O capability when your automation requirements exceed the standard 16 digital inputs and 16 relay outputs. Expansion modules can be added as needed, allowing for greater system flexibility as your control tasks grow more complex.

Q: Where can I mount the Vigor VB2-32MP-D controller in my facility?

A: The PLC is designed for ease of installation and can be mounted on a DIN rail or directly to a panel within your control cabinet. Its compact size ensures it integrates smoothly into most industrial setups.

Q: What is the process for connecting the VB2-32MP-D to other control systems?

A: Connection is established through the onboard RS232 communication port. For more complex network requirements, additional expansion ports are available. This allows for integration with supervisory systems, touch panels, or data logging equipment.

Q: How does the indicator LED functionality benefit users?

A: The input/output status LEDs provide instant visual feedback, allowing operators and maintenance personnel to quickly monitor system states, diagnose issues, and verify correct operation without needing additional diagnostic devices.

Q: What are the advantages of using this PLC for automation projects?

A: Key benefits include reliable digital control, modular expansion, intuitive ladder logic programming, robust construction (ABS and electronic components), and compliance with CE and RoHS standards. These features ensure dependable operation and easy maintenance, supporting efficient industrial automation.
