MEAN WELL DR-120-24 Single-Phase, 120-Watt Industrial DIN Rail Power Supply

Send Inquiry

Request To Call Back

MEAN WELL DR-120-24 Single-Phase, 120-Watt Industrial DIN Rail Power Supply

Name: MEAN WELL DR-120-24 Single-Phase, 120-Watt Industrial DIN Rail Power Supply
Brand: Industrial Online Services
Price: 15000 INR
Availability: InStock

Price 15000 INR/ Number

Get a Price/Quote

MOQ : 1 Piece

MEAN WELL DR-120-24 Single-Phase, 120-Watt Industrial DIN Rail Power Supply Specification

Humidity
20% to 90% RH (non-condensing)

Phase
Single Phase

Rated Voltage
24V DC

Output Voltage
24V DC

Operating Temperature
-10C to +60C

Frequency
47-63 Hz

Protection Level
Overload, Overvoltage, Short Circuit Protection

Input Current
2.3A/115V, 1.3A/230V

Efficiency
up to 87%

Mounting Type
DIN Rail Mountable

Main Material
Metal casing

Processing Type
Switching Power Supply

Condition
New

Function
Converts AC input to regulated 24V DC output

Application
Industrial Automation, Control Panels, DIN Rail Mounting

Dimension (L*W*H)
125.2mm x 100mm x 65.5mm

Power Mode
Single Phase AC to DC Conversion

Voltage
Input: 180-264VAC, Output: 24VDC

Power Consumption
120 Watts (Rated output)

Battery Life
Not Applicable (AC powered)

Accessories
None included

Cooling Method
Natural air convection

Output Current
5A

LED Indicator
Power On indication

Adjustable Output Voltage Range
22V to 27.5V DC

Overload Protection
105-150% rated output power

Installation Type
TS-35/7.5 or TS-35/15 DIN Rail

MEAN WELL DR-120-24 Single-Phase, 120-Watt Industrial DIN Rail Power Supply Trade Information

Minimum Order Quantity
1 Piece

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About MEAN WELL DR-120-24 Single-Phase, 120-Watt Industrial DIN Rail Power Supply

MEAN WELL DR-120-24 Single-Phase, 120-Watt Industrial DIN Rail Power Supply

Core Specifications

The primary operational ratings and electrical metrics for this power supply module include:

Output Voltage: 24V DC (Adjustable via a front potentiometer from 24V to 28V).
Output Current: 0 to 5 Amperes.
Total Rated Power: 120 Watts max.
AC Input Range: 88132 VAC or 176264 VAC (Selectable via a manual toggle switch on the device).
DC Input Support: Supports 248370 VDC.
Efficiency: Typically 84%.
Form Factor & Enclosure: Heavy-duty metal casing measuring 65.5mm (W) x 125mm (H) x 100mm (D) and weighing approximately 790g.
Mounting Type: Snaps onto standard TS-35/7.5 or TS-35/15 industrial DIN rails.

Reliable Power for Industrial Automation

The MEAN WELL DR-120-24 is specifically designed for industrial automation and control panels, offering dependable 24V DC output for sensitive equipment. With high efficiency, multiple safety features, and robust construction, this DIN rail power supply supports uninterrupted operation in challenging industrial environments. Its adjustable output and natural convection cooling further enhance reliability, making it a preferred choice among industry professionals.

Easy Installation and Flexible Configuration

Featuring standard TS-35/7.5 or TS-35/15 DIN rail compatibility, installing the DR-120-24 is straightforward in control cabinets and industrial enclosures. The output voltage is adjustable for various application needs, while the built-in power-on LED provides clear visual feedback. Regardless of installation demands, its compact design and user-friendly mounting process ensure seamless integration into existing systems.

FAQ's of MEAN WELL DR-120-24 Single-Phase, 120-Watt Industrial DIN Rail Power Supply:

Q: How do I mount the MEAN WELL DR-120-24 power supply in my control panel?

A: The DR-120-24 is designed for quick installation on TS-35/7.5 or TS-35/15 standard DIN rails. Simply align the mounting bracket on the unit with the rail and snap it into place securely. This design allows effortless integration into most industrial control panels.

Q: What type of protection features does the DR-120-24 offer?

A: This power supply provides comprehensive protection, including overload (105-150% of rated output power), overvoltage, and short circuit protection. These features safeguard both the unit and connected equipment from damage due to abnormal operating conditions.

Q: When should I use the output voltage adjustment feature?

A: The adjustable output voltage range of 22V to 27.5V DC allows you to tailor the output to match the requirements of your specific devices or system, enhancing flexibility for different industrial applications. Adjust the potentiometer on the front panel as needed.

Q: Where is the DR-120-24 most commonly used?

A: The DR-120-24 is widely implemented in industrial automation, factory control panels, and other DIN rail-mounted applications where reliable 24V DC power is essential. Its sturdy construction and dependable performance make it suitable for demanding environments.

Q: What is the benefit of natural air convection cooling in this unit?

A: Natural air convection removes the need for cooling fans, reducing moving parts and potential points of failure. This design results in quieter operation, increased lifespan, and lower maintenance requirements for the power supply.

Q: How efficient is the DR-120-24 power supply?

A: The DR-120-24 delivers up to 87% efficiency, minimizing energy waste and ensuring lower operating temperatures. Its high efficiency also translates to reduced energy costs for industrial users.
