LENZE E82EV152-4C 1.5 kW (2.0 HP) Variable Frequency Drive (VFD)

Name: LENZE E82EV152-4C 1.5 kW (2.0 HP) Variable Frequency Drive (VFD)
Brand: Industrial Online Services
Price: 15000 INR
Availability: InStock

Price 15000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

LENZE E82EV152-4C 1.5 kW (2.0 HP) Variable Frequency Drive (VFD) Specification

Model No
E82EV152-4C

Chip Type
Industrial Drive Controller

I/O Cards Type
Digital & Analog I/O Supported via Expansion Modules

Condition
Used

Compatible Port/Slot
Standard Terminal Block Connections

Use
Variable Frequency Drive (VFD) for Motor Control

Frequency Range
0 - 650 Hz

Cooling Type
Forced air/cooled by internal fan

Display
Status LEDs, Optional Keypad Module

Output Current
4.1A

Application
Suitable for controlling AC induction motors in industrial automation

Dimensions
225mm x 100mm x 185mm (H x W x D)

Output Voltage
0-480V AC Three Phase (Variable)

Standards Compliance
CE, UL, cUL

Communication Interfaces
Optional (e.g. CANopen, Profibus, EtherCAT via expansion)

Input Voltage
380-480V AC Three Phase

Enclosure Rating
IP20

Series
8200 vector

Power Rating
1.5 kW (2.0 HP)

Net Weight
1.8 kg

Control Method
V/f (Voltage/Frequency) Control, Sensorless Vector Control

Mounting
Panel Mount

LENZE E82EV152-4C 1.5 kW (2.0 HP) Variable Frequency Drive (VFD) Trade Information

Minimum Order Quantity
1 Piece

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About LENZE E82EV152-4C 1.5 kW (2.0 HP) Variable Frequency Drive (VFD)

LENZE E82EV1524C 15 kW 20 HP Variable Frequency Drive VFD

Key Specifications

Power Rating 15 kW 20 HP

Input Voltage 3phase AC 400V to 500V 5060 Hz

Mains Current 55 A at 400V 44 A at 500V

Output Ratings 3phase AC 0400V500V 39 A 31 A

Output Frequency 0 to 650 Hz

Control Modes Sensorless Vector Control and VHz Vf Control

Enclosure Rating IP20 protection class

Dimensions Weight 60 mm width 180 mm height 130 mm depth weighs approximately 16 kg

Key Features

Modular Integration Supports plugin communication modules including CAN bus Profibus and standard IO extensions

Builtin Protection Outfitted with integrated electronic protection against overvoltage short circuits overloading and overheating

Dynamic Control Offers an integrated braking unit for demanding deceleration tasks and high energy efficiency 97

Comprehensive Motor Control for Industrial Automation

The LENZE E82EV152-4C VFD provides advanced features to efficiently control three-phase AC induction motors. With flexible control options, including standard V/f and sensorless vector methods, it is well-suited for diverse automation requirements. The drive's broad frequency range (0-650 Hz) allows for precise speed regulation, supporting optimal process performance.

Versatile Connectivity and Expansion Options

Equipped with standard terminal block connections, the drive supports both digital and analog I/O modules. Optional communication expansion cards allow for seamless integration with fieldbus protocols such as CANopen, Profibus, or EtherCAT. This flexibility ensures easy adaptability to various industrial network architectures.

Reliable Performance and User-Friendly Design

Housed in an IP20-rated enclosure and cooled via an internal fan, the LENZE E82EV152-4C VFD delivers reliable operation even in challenging environments. Status LEDs and an optional keypad module facilitate straightforward monitoring and on-site configuration, making installation and maintenance convenient.

FAQ's of LENZE E82EV152-4C 1.5 kW (2.0 HP) Variable Frequency Drive (VFD):

Q: How does the LENZE E82EV152-4C VFD benefit industrial automation systems?

A: This VFD enables precise speed and torque control of AC induction motors, improving process efficiency and adaptability. Its flexible control modes and communication interfaces support integration into a wide range of automation systems.

Q: What is the recommended installation process for the LENZE E82EV152-4C?

A: The unit is designed for panel mounting and should be installed in a well-ventilated area to ensure adequate cooling. Standard terminal blocks simplify wiring, and optional modules can be added for additional I/O or communication requirements.

Q: When is sensorless vector control preferred over V/f control on this drive?

A: Sensorless vector control is ideal when enhanced motor performance, such as higher starting torque or more accurate speed regulation, is required, whereas V/f control is suitable for general-purpose applications.

Q: Where can the LENZE E82EV152-4C be used?

A: This VFD is suitable for applications in industrial automation, such as conveyor systems, pumps, fans, and other machinery that utilize three-phase AC induction motors within its rated power and voltage specifications.

Q: What communication protocols are supported by the LENZE E82EV152-4C?

A: The drive supports optional communication interfaces, including CANopen, Profibus, and EtherCAT, through expansion cards, enabling integration with modern industrial network systems.

Q: How can users monitor and configure the drive settings?

A: Essential operating status is displayed via onboard LEDs. For enhanced monitoring and parameter setting, users can connect an optional keypad module, facilitating easy on-site configuration.
