PEPPERL & FUCHS KFD2-SR2-EX1.W 1-Channel Isolated Switch Amplifier (Intrinsic Safety Barrier)

Name: PEPPERL & FUCHS KFD2-SR2-EX1.W 1-Channel Isolated Switch Amplifier (Intrinsic Safety Barrier)
Brand: Industrial Online Services
Price: 5000 INR
Availability: InStock

Price 5000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

PEPPERL & FUCHS KFD2-SR2-EX1.W 1-Channel Isolated Switch Amplifier (Intrinsic Safety Barrier) Specification

Rated Voltage
24 V DC

Protection Level
IP20

Input Current
Input: 3 mA (Typical Switch Current)

Humidity
Max. 95% RH, Non-Condensing

Operating Temperature
-20C to +60C

Efficiency
High Electrical Isolation Efficiency

Frequency
DC/Low Frequency (Switching Applications)

Output Voltage
Passive NO/NC Relay Output (max. 250 V AC, 40 V DC)

Mounting Type
DIN Rail

Main Material
Plastic Enclosure, Electronic Components

Processing Type
Electronics

Condition
New

Function
Isolated Switch Amplifier for Intrinsically Safe Inputs

Application
Signal Isolation and Switching in Intrinsically Safe Circuits

Dimension (L*W*H)
Approx. 114 mm x 18 mm x 110 mm

Power Mode
DC Powered

Voltage
20...35 V DC (Rated: 24 V DC)

Power Consumption
Approx. 1.7 W

Accessories
None Included

Switching Current
Max. 2 A

Terminals
Screw Type

Intrinsically Safe Approval
Yes (EEx ia)

Signal Transmission
Electromechanical Relay Changeover Contact (SPDT)

Relay Output Contact Rating
2 A at 250 V AC, 2 A at 40 V DC (resistive load)

Switching Voltage
Max. 253 V AC / 40 V DC

Compatible Signals
NAMUR Sensors, Contact Switches

Number of Channels
1 Channel

Response Time
<10 ms

Model
KFD2-SR2-EX1.W

Category
Isolated Barrier / Switch Amplifier

Weight
Approx. 110 g

Enclosure Material
Polyamide (Green Housing)

PEPPERL & FUCHS KFD2-SR2-EX1.W 1-Channel Isolated Switch Amplifier (Intrinsic Safety Barrier) Trade Information

Minimum Order Quantity
1 Piece

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About PEPPERL & FUCHS KFD2-SR2-EX1.W 1-Channel Isolated Switch Amplifier (Intrinsic Safety Barrier)

PEPPERL & FUCHS KFD2-SR2-EX1.W 1-Channel Isolated Switch Amplifier (Intrinsic Safety Barrier)

Key Specifications

Power Supply: 19 to 30 V DC via Power Rail or terminals.
Input Type: Confirms to EN 60947-5-6 standards for NAMUR proximity sensors or volt-free mechanical dry contacts.
Output Type: Relay output consisting of 1 changeover contact.
Safety Integrity Level: Rated up to SIL 2 (SC 3) compliant with IEC/EN 61508.
Diagnostics: Built-in Line Fault Detection (LFD) to identify short circuits or broken wiring.
Control Function: Reversible mode of operation adjusted using integrated DIP switches.

High-Performance Signal Isolation

Engineered for demanding environments, the KFD2-SR2-EX1.W delivers optimal isolation between control and field circuits, ensuring safe signal transmission. Its compatibility with NAMUR sensors and contact switches makes it versatile for a wide range of applications. Quick response times and high switching ratings further support efficiency in process control.

Designed for Intrinsic Safety

This switch amplifier meets stringent EEx ia safety standards for use in hazardous zones, protecting both your equipment and personnel. The polyamide enclosure provides durability, and screw-type terminals facilitate secure wiring connections. IP20 protection and wide operating conditions ensure continued performance.

Effortless Integration and Operation

Installation is streamlined with DIN rail mounting and simple screw terminals, catering to busy industrial environments. Its passive relay output, compatibility with standard control voltages, and compact dimensions support seamless integration into existing automation setups, reducing downtime and maintenance costs.

FAQ's of PEPPERL & FUCHS KFD2-SR2-EX1.W 1-Channel Isolated Switch Amplifier (Intrinsic Safety Barrier):

Q: How is the KFD2-SR2-EX1.W isolated switch amplifier typically used in industrial applications?

A: The KFD2-SR2-EX1.W is mainly used for isolating and amplifying signals from field devices such as NAMUR sensors and contact switches in hazardous environments. It transmits these signals safely to control systems, ensuring reliable operation in process automation and control circuits.

Q: What are the primary benefits of using this switch amplifier?

A: Key benefits include high electrical isolation efficiency, intrinsic safety compliance (EEx ia), fast response times, and a robust, maintenance-friendly design. These features protect sensitive equipment, improve safety, and minimize downtime in industrial automation.

Q: When should this amplifier be installed in a control system?

A: This device should be installed whenever there is a need to connect intrinsically safe field devices to non-intrinsically safe control systems, particularly in hazardous areas where explosion protection is required.

Q: Where can the KFD2-SR2-EX1.W be mounted for optimal performance?

A: The amplifier is designed for DIN rail mounting, making it suitable for installation in control panels or distribution boxes within industrial plants, provided the environment meets the IP20 protection rating and ambient conditions.

Q: What types of signals are compatible with the KFD2-SR2-EX1.W?

A: It accepts input from NAMUR sensors and mechanical contact switches, making it versatile for various signaling and monitoring tasks in process automation and industrial environments.

Q: How does the device ensure intrinsic safety in hazardous areas?

A: By providing electrical isolation between unsafe field circuits and safe control circuits, and adhering to EEx ia standards, the device prevents sparks or heat build-up that could ignite flammable atmospheres.

Q: What process is involved in wiring and commissioning this amplifier?

A: Wiring is performed via screw-type terminals, and the compact design enables easy DIN rail mounting. After installation, the amplifier operates automatically, requiring only supply voltage and connection of the field and control signals.
