Clipsal L5508DSIP C-Bus2 DSI Gateway Relay Module

Send Inquiry

Request To Call Back

Clipsal L5508DSIP C-Bus2 DSI Gateway Relay Module

Name: Clipsal L5508DSIP C-Bus2 DSI Gateway Relay Module
Brand: Industrial Online Services
Price: 10000 INR
Availability: InStock

Price 10000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Clipsal L5508DSIP C-Bus2 DSI Gateway Relay Module Specification

Output Voltage
9 to 17 V DC (DSI standard)

Rated Voltage
230 V AC

Input Current
Max 100 mA

Frequency
50/60 Hz

Humidity
0 to 95% non-condensing

Phase
Single phase

Mounting Type
DIN Rail

Efficiency
High-efficiency switching

Operating Temperature
0C to 45C

Protection Level
IP20

Main Material
Polycarbonate enclosure

Processing Type
Electronic Relay/Gateway Module

Condition
New

Function
C-Bus2 to DSI digital signal interface

Application
Lighting automation and DSI ballast control

Dimension (L*W*H)
215 mm (W) x 85 mm (D) x 65 mm (H)

Power Mode
Mains powered

Voltage
230 V AC, 50/60 Hz

Power Consumption
<10 W

Accessories
DIN rail mounting kit included

Approval Standards
AS/NZS, CE Conformity

Module Weight
Approx. 0.75 kg

Compatibility
Compatible with all C-Bus2 control systems

Enclosure Colour
Grey

Relay Type
Solid State and Zero Cross switching

Status Indicators
LED status indicators per channel and system

DSI Devices Supported
Up to 8 DSI ballasts per channel (max 64 ballasts)

Control Interface
C-Bus2 twisted pair network

Isolation
Electrically isolated C-Bus and DSI

Channels
8 independent DSI output channels

Clipsal L5508DSIP C-Bus2 DSI Gateway Relay Module Trade Information

Minimum Order Quantity
1 Piece

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About Clipsal L5508DSIP C-Bus2 DSI Gateway Relay Module

Clipsal L5508DSIP CBus2 DSI Gateway Relay Module

The Clipsal L5508DSIP is a premium Schneider Electric CBus 8Channel Digital Serial Interface DSI Gateway Dimmer Module engineered for advanced building automation and lighting control systems This network component bridges the CBus control protocol with DSIcompliant digital dimmable electronic ballasts such as AtcoTridonic brands to facilitate precise largescale commercial or highend residential lighting management

Core Specifications

Channels 8 independent DSI channels

Load Capacity Drives up to 100 DSI ballasts per channel enabling management of up to 800 ballasts total via a single module

Output Current 200 mA per channel maximum with a total aggregated module output threshold of 270 mA

Operating Voltage Designed for universal mains integration across 110120V AC or 220240V AC at a frequency range of 5060 Hz

Form Factor Standard DIN rail mounted design occupying 12 modules 215 mm total width inside electrical distribution boards

Seamless Integration with C-Bus2 and DSI Ballasts

This relay module is fully compatible with C-Bus2 control systems, making it easy to integrate into new or existing lighting automation setups. Its DSI output channels support modern digital ballast control, giving building operators enhanced flexibility and scalability.

Reliable and Safe Performance

Featuring solid-state, zero cross switching relays and electrical isolation between C-Bus and DSI networks, the L5508DSIP guarantees safe, efficient operation and extends the longevity of your lighting infrastructure. Built to global standards, it meets requirements for AS/NZS and CE, with IP20 protection.

Practical Design and Efficient Operation

Mounting is straightforward with the included DIN rail kit, and onboard LED status indicators make diagnostics simple. High-efficiency output and low power draw (<10 W) ensure energy-saving operation. The durable enclosure and wide environmental tolerance enable versatile installation.

FAQ's of Clipsal L5508DSIP C-Bus2 DSI Gateway Relay Module:

Q: How does the Clipsal L5508DSIP module connect C-Bus2 systems with DSI-compatible lighting?

A: The L5508DSIP module acts as an interface between a C-Bus2 control network and DSI-controlled lighting ballasts, translating commands from the C-Bus2 system into DSI signals that manage up to 8 ballasts per channel.

Q: What is the maximum number of DSI ballasts this relay module can support?

A: The module supports up to 8 independent channels, each connecting up to 8 DSI ballasts, allowing for a total of 64 DSI ballasts.

Q: Where is the L5508DSIP typically installed, and what mounting method is used?

A: This gateway module is designed for DIN rail mounting within commercial or industrial distribution boards, ensuring quick, secure installation and easy integration with electrical infrastructure.

Q: What are the benefits of the solid-state, zero cross relay switching in this device?

A: Solid-state, zero cross relay switching ensures minimal wear and tear, reduces electrical noise, and extends the lifespan of connected equipment by switching only at zero voltage crossings of the AC waveform.

Q: How do users monitor the operational status of the module or each DSI channel?

A: Front-mounted LED status indicators provide quick visual feedback on the activity and status of each individual channel, as well as overall system health, facilitating fast diagnostics and maintenance.
