KS VARIO KSVC-101-00111-U00 PROFIBUS-DP/V1 Fieldbus Coupler / Bus Terminal Module

Send Inquiry

Request To Call Back

KS VARIO KSVC-101-00111-U00 PROFIBUS-DP/V1 Fieldbus Coupler / Bus Terminal Module

Name: KS VARIO KSVC-101-00111-U00 PROFIBUS-DP/V1 Fieldbus Coupler / Bus Terminal Module
Brand: Industrial Online Services
Price: 15000 INR
Availability: InStock

Price 15000 INR/ Number

Get a Price/Quote

MOQ : 1 Piece

KS VARIO KSVC-101-00111-U00 PROFIBUS-DP/V1 Fieldbus Coupler / Bus Terminal Module Specification

Frequency
Not applicable - DC device

Operating Temperature
0 to +55C

Input Current
Approx. 120 mA at 24 V DC

Mounting Type
DIN rail mounting

Rated Voltage
24 V DC

Humidity
5% to 95% (non-condensing)

Protection Level
IP20

Main Material
Industrial-grade plastic and electronic components

Processing Type
Electronic module

Condition
Used

Function
Fieldbus coupler for Profibus-DP/V1, connects I/O modules to fieldbus network

Application
Profibus-DP/V1 fieldbus interface, PLC/automation systems

Dimension (L*W*H)
Approx. 120 x 100 x 40 mm

Power Mode
Powered by external supply

Voltage
24 V DC (typical)

Power Consumption
Approx. 2.5 W

Accessories
Not included

Supported Protocols
Profibus-DP/V1

Terminal Connections
Screw-type terminals for I/O coupling

Product Series
KS vario

Article Number
KSVC-101-00111-U00

Weight
Approx. 180 g

Isolation
Galvanic isolation between fieldbus and I/O lines

Bus Interface
Profibus-DP/V1, Sub-D 9-pin female connector

Status Display
LED indicators for operation and errors

KS VARIO KSVC-101-00111-U00 PROFIBUS-DP/V1 Fieldbus Coupler / Bus Terminal Module Trade Information

Minimum Order Quantity
1 Piece

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About KS VARIO KSVC-101-00111-U00 PROFIBUS-DP/V1 Fieldbus Coupler / Bus Terminal Module

KS VARIO KSVC-101-00111-U00 PROFIBUS-DP/V1 Fieldbus Coupler / Bus Terminal Module

Key Specifications & Features

Component Type: Fieldbus Coupler / Bus Terminal Module (KS VARIO BK DP/V1)
Protocol Support: Standard PROFIBUS-DP and extension DP/V1
Operating Voltage: 24 V DC
System Functionality: Connects the modular KS Vario controller system to the central PLC or supervisor network. It powers the internal system bus for all interconnected I/O expansion modules (handling up to 30 control loops, 60 analog outputs, or 320 digital I/O points).

Reliable Fieldbus Integration

The KS VARIO KSVC-101-00111-U00 serves as a dependable bridge between I/O modules and Profibus-DP/V1 fieldbus networks. Its robust construction and effective galvanic isolation ensure signal integrity and operational safety in demanding automation environments, making it a preferred choice for industrial applications.

Flexible and Easy Installation

Designed with a DIN rail mounting system and compact dimensions, this fieldbus coupler allows for straightforward integration within control panels. Screw-type terminals facilitate secure I/O coupling, while LED indicators simplify troubleshooting, ensuring minimal downtime during setup and maintenance.

Industrial-grade Performance

Built from high-quality plastic and electronic components, the module is rated for temperatures from 0 to +55C and humidity levels up to 95% (non-condensing). Its IP20 protection makes it suitable for enclosed spaces, guaranteeing durability and consistent performance in automated operations.

FAQ's of KS VARIO KSVC-101-00111-U00 PROFIBUS-DP/V1 Fieldbus Coupler / Bus Terminal Module:

Q: How do I connect the KSVC-101-00111-U00 to a Profibus-DP/V1 network?

A: You can connect the coupler to your Profibus-DP/V1 network using its Sub-D 9-pin female connector. Simply attach the Profibus cable to the corresponding port and secure your I/O wiring through the screw-type terminals provided.

Q: What is the primary function of this fieldbus coupler in automation systems?

A: The primary purpose of the KSVC-101-00111-U00 is to interface field I/O modules with a Profibus-DP/V1 fieldbus network, facilitating seamless data exchange between your automation devices and the fieldbus system.

Q: When should I check the LED status indicators on the module?

A: It's recommended to monitor the LED indicators during operation and troubleshooting. These LEDs provide real-time feedback on operational status and error conditions, helping identify network or module issues quickly.

Q: Where can the KSVC-101-00111-U00 be mounted within a control system?

A: This module is designed for DIN rail mounting inside control cabinets or automation panels, ensuring ease of access and a secure installation environment.

Q: What process should I follow for installation and power supply connection?

A: Install the coupler onto a DIN rail, connect your Profibus and I/O cables securely, and power the unit using a 24 V DC external supply. Ensure wiring is correct before activating the system to avoid operational errors.

Q: How does galvanic isolation benefit the device and connected systems?

A: Galvanic isolation separates the fieldbus signals from the I/O circuitry, protecting sensitive components from voltage spikes and ground loops, thus enhancing overall system reliability and safety.

Q: What are the advantages of using the KS VARIO KSVC-101-00111-U00 in industrial automation?

A: This module offers robust connectivity, effective isolation, clear fault indication, flexible mounting, and compatibility with a wide range of Profibus-DP/V1-based automation setups, making it a versatile solution for industrial control systems.
