Wago 750-461 PLC 2-Channel Analog Input Module

Wago 750-461 PLC 2-Channel Analog Input Module About

Wago 750461 PLC 2Channel Analog Input Module

The WAGO 750461 is a 2channel analog input module designed specifically to connect directly to Pt100 RTD resistance sensors for precise temperature measurement within the WAGO IO System 750

Key Technical Specifications

Channels 2 analog inputs

Sensor Compatibility Pt100 RTD sensors supporting both 2wire and 3wire sensor connections

Temperature Range Measures from 200 C to 850 C

Resolution 01 C across the entire measurement range

Conversion Time  320 ms typical

Internal Diagnostics Builtin red error LEDs illuminate to indicate short circuits line breaks or measurement range overflows Green LEDs indicate normal operational readiness

Wiring System Utilizes 8 CAGE CLAMP termination points ensuring vibrationproof connections for conductors ranging from 008 to 25 mm 2814 AWG

Dimensions 12 mm wide 100 mm high and 698 mm deep

Form Factor Compact IP20rated housing that snaps directly onto standard DIN rails
