ALLEN BRADLEY 1746-OB16 16-Channel Digital DC Sourcing Output Module

About ALLEN BRADLEY 1746-OB16 16-Channel Digital DC Sourcing Output Module

Technical Specifications

• Outputs: 16 transistor outputs organized in a single group (1 common point).
• Operating Voltage Range: 10 to 50V DC (Sourcing type).
• Backplane Current Draw: 0.280 A at 5V DC and 0 A at 24V DC.
• Continuous Output Current: 0.5 Amps per point at 60 C (maximum aggregate current reaches 8 Amps per module at 30 C).
• Surge Current capacity: 3.0 Amps for 10 milliseconds per point.
• Signal Delay Times: Max 0.1 ms from off-to-on; max 1.0 ms from on-to-off.
• Termination Type: Includes a removable terminal block (Replacement Part: 1746-RT25).
• Status Indicators: Front-facing LED displays indicating the active state of each individual I/O channel.
