Allen-Bradley 25B-D4P0N104 AC variable frequency drive

Name: Allen-Bradley 25B-D4P0N104 AC variable frequency drive
Brand: Industrial Online Services
Price: 35000 INR
Availability: InStock

Price 35000 INR/ Number

Get a Price/Quote

MOQ : 1 Piece

Allen-Bradley 25B-D4P0N104 AC variable frequency drive Specification

Chip Type
Integrated Power Module

Model No
25B-D4P0N104

I/O Cards Type
Digital/Analog I/O

Condition
Used / Refurbished

Compatible Port/Slot
Panel/Chassis Mount

Use
Industrial Automation, Motor Speed Control

Series
PowerFlex 525

Communication Options
EtherNet/IP, Modbus RTU, USB

Output Current
4.0A

Enclosure Type
IP20 Open Type

Display Type
LCD Keypad

Mounting
Panel Mount

Dimensions (HxWxD)
143 x 72 x 151 mm approx.

Ambient Operating Temp
-10C to +50C

Weight
1.1 kg

Frequency Range
0-400 Hz

Output Power
1.5 kW / 2 HP

Safety Features
Electronic Motor Protection, Fault Diagnostics

Standards
IEC/UL/cUL, CE Marked

Motor Control Type
V/Hz, Sensorless Vector Control

Input Voltage
380-480V AC 3-Phase

Allen-Bradley 25B-D4P0N104 AC variable frequency drive Trade Information

Minimum Order Quantity
1 Piece

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About Allen-Bradley 25B-D4P0N104 AC variable frequency drive

Allen-Bradley 25B-D4P0N104 AC variable frequency drive

Core Specifications

Power Rating: 1.5 kW (2.0 Horsepower) for both normal and heavy-duty operation.
Input Voltage: 3-phase, 380 to 480 Volts AC (50/60 Hz).
Output Current: 4.0 Amps.
Frame Size: Frame A (compact footprint supporting "Zero Stacking" mounting with minimal airflow gaps).
Enclosure Rating: IP20 / NEMA Open Type (designed for controlled, clean panel environments).
EMC Filter: No internal filter.
Key Features & Capabilities
- Control Methods: Supports Volts per Hertz (V/Hz), Sensorless Vector Control (SVC), Closed Loop Velocity Vector Control, and Permanent Magnet Motor Control.
- Integrated Communication: Features an embedded EtherNet/IP port, a USB port for configuration configuration, and an RS485 connection.
- Built-in Safety: Out-of-the-box Safe Torque-Off (STO) certified at PLd/SIL2 Cat 3, eliminating rotational power without removing drive power.
- Braking Mechanism: Includes a standard integrated IGBT braking module.
- I/O Configuration: Features 7 discrete inputs (sink/source), 2 digital outputs, 2 analog inputs, and 1 analog output.

Versatile Motor Control Solutions

The PowerFlex 525 series drive supports a wide frequency range and dual control types, enabling reliable speed and torque management for a broad spectrum of industrial motors. Its robust design ensures uninterrupted operation across varied applications like conveyors, pumps, fans, and mixers.

Simplified Installation and Flexible Communication

Installation is made straightforward with panel mounting and compact dimensions. Built-in Ethernet/IP, Modbus RTU, and USB connectivity streamline device integration and remote monitoring, facilitating rapid deployment in both new and retrofit Industrial Automation systems.

Comprehensive Protection and Diagnostics

Integrated electronic motor protection enhances safety and equipment longevity by preventing overloads and faults. Detailed fault diagnostics and a user-friendly LCD keypad make setup, monitoring, and troubleshooting straightforward, reducing downtime and maintenance effort.

FAQ's of Allen-Bradley 25B-D4P0N104 AC variable frequency drive:

Q: How is the Allen-Bradley 25B-D4P0N104 VFD installed and mounted?

A: This drive features a panel mount design and can be securely installed in standard industrial control panels or chassis slots. Its compact dimensions (143 x 72 x 151 mm) allow it to fit into tight spaces, ideal for upgrades or new system integration.

Q: What types of motors and applications are best suited for this variable frequency drive?

A: The 25B-D4P0N104 is suitable for 3-phase industrial motors up to 1.5 kW (2 HP) and operates efficiently in applications like conveyors, pumps, fans, mixers, and other machinery requiring variable speed control.

Q: When should I use the V/Hz versus Sensorless Vector Control modes?

A: V/Hz control is ideal for simple speed regulation and energy savings, while Sensorless Vector Control enhances torque and dynamic response, making it preferable for applications that demand greater precision or variable loads.

Q: Where can this VFD be used, considering environmental factors?

A: With an operational temperature range from -10C to +50C and an IP20 open-type enclosure, this drive is designed for use inside protective industrial panels in non-condensing, indoor environments.

Q: What process does the VFD use to protect motors and reduce downtime?

A: It employs electronic motor protection and advanced fault diagnostics to monitor operation, shut down under abnormal conditions, and provide clear alerts, thus preventing damage and facilitating quick corrective actions.

Q: How does the built-in communication capability benefit industrial automation?

A: With EtherNet/IP, Modbus RTU, and USB options, the drive enables seamless integration with modern control systems, supports remote diagnostics, and allows parameter adjustments, which simplifies management and boosts operational efficiency.
