ALLEN BRADLEY 1746-IV16 16-Channel Discrete DC Input Module

Name: ALLEN BRADLEY 1746-IV16 16-Channel Discrete DC Input Module
Brand: Industrial Online Services
Price: 15000 INR
Availability: InStock

Price 15000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

ALLEN BRADLEY 1746-IV16 16-Channel Discrete DC Input Module Specification

Model No
1746-IV16

Chip Type
Input Module

I/O Cards Type
16-Channel Discrete DC Input

Condition
Used/Refurbished

Compatible Port/Slot
SLC 500 Chassis

Use
Industrial Automation, PLC Systems

OS Supported
Not Applicable (PLC Hardware)

Mounting
SLC 500 Modular Chassis

Input Current
8mA @ 24VDC

Number of Inputs
16

Dimensions
Approx. 4in x 6in x 2in

Weight
Approx. 0.45 kg (1 lb)

Replacement for
SLC 500 Series Digital Input Module

Connection Type
Backplane/Terminal Block

Module Type
Digital Input Module

Status Indicators
LEDs for each input channel

Operating Temperature
0 to 60C (32 to 140F)

Isolation Voltage
500V AC, 1 min

Voltage Range
10-30V DC

ALLEN BRADLEY 1746-IV16 16-Channel Discrete DC Input Module Trade Information

Minimum Order Quantity
1 Piece

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About ALLEN BRADLEY 1746-IV16 16-Channel Discrete DC Input Module

ALLEN BRADLEY 1746-IV16 16-Channel Discrete DC Input Module

Core Specifications

Channels: 16 discrete input channels arranged in 1 single group.
Input Type: Sourcing configuration.
Nominal Input Voltage: 24V DC.
Operating Voltage Range: 10 to 30V DC.
Nominal Input Current: 8 mA at 24V DC.
Backplane Current Consumption: 85 mA at 5V DC.
Maximum Off-State Voltage: 5V DC.
Operating Temperature: 0C to 60C (32F to 140F).
Isolation Ratings: 1500V AC backplane isolation; 500V DC communication circuit isolation.
Connection Interface: Removable terminal block with screw connections.

Industrial Automation Made Simple

The Allen Bradley 1746-IV16 module streamlines digital input operations for diverse industrial environments. With the ability to handle 16 discrete DC input channels, it's ideal for automation projects requiring reliable signal monitoring and processing. Its ergonomic design and robust construction offer easy integration with SLC 500 modular chassis, making setup and maintenance both efficient and accessible.

Reliable Performance and Enhanced Safety

Enjoy peace of mind with each input channel isolated up to 500V AC for one minute, safeguarding your system and personnel. LED indicators provide clear, instant input status, reducing troubleshooting time and operational hazards. With a broad operating temperature range (0-60C), the 1746-IV16 excels in varying industrial settings.

FAQ's of ALLEN BRADLEY 1746-IV16 16-Channel Discrete DC Input Module:

Q: How do I install the Allen Bradley 1746-IV16 digital input module into my PLC system?

A: To install the 1746-IV16 module, simply align it with the appropriate slot in your SLC 500 modular chassis and push it securely into place. Connect the terminal block or backplane as per your system configuration, and ensure all wiring matches the voltage and current specifications.

Q: What are the main benefits of using the 1746-IV16 module in industrial automation?

A: The 1746-IV16 offers enhanced reliability, 16 independent DC input channels, and efficient system integration. Its status LEDs allow for quick diagnostics, while electrical isolation helps protect the system from voltage surges, resulting in safer and more consistent operation.

Q: When should I consider replacing my SLC 500 Series digital input module with the 1746-IV16?

A: Replacement should be considered when the existing module shows frequent faults, intermittent input detection, or physical wear. The 1746-IV16 serves as a direct, compatible replacement that restores reliable digital input performance for SLC 500 PLC systems.

Q: Where is the ideal environment to use the Allen Bradley 1746-IV16 module?

A: This module is best used in controlled industrial settings such as manufacturing plants, process facilities, and automated production lines-anywhere within the operating temperature range of 0 to 60C and where DC voltage between 10 and 30V is available.

Q: What process is followed to verify input signals on the 1746-IV16?

A: Each input signal's status can be verified using the front-panel LED indicators; a lit LED signifies an active (input high) channel. This facilitates immediate monitoring and troubleshooting without the need for external instruments.

Q: Is the 1746-IV16 compatible with various slot types in the SLC 500 chassis?

A: Yes, the 1746-IV16 is specifically designed for the SLC 500 chassis, making it compatible with any standard slot within this modular system. Always refer to your chassis documentation for optimal slot placement.
