BECKHOFF BK5250 DeviceNet Compact Bus Coupler

Name: BECKHOFF BK5250 DeviceNet Compact Bus Coupler
Brand: Industrial Online Services
Price: 5000 INR
Availability: InStock

Price 5000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

BECKHOFF BK5250 DeviceNet Compact Bus Coupler Specification

Mounting Type
DIN rail mounting

Operating Temperature
0C to +55C

Rated Voltage
24 V DC

Input Current
Max 500 mA (at 24 V DC)

Phase
Single phase

Efficiency
High; industrial automation grade

Humidity
Up to 95% non-condensing

Protection Level
IP20

Main Material
Industrial grade plastic housing

Processing Type
Bus coupler for DeviceNet

Condition
Used / Refurbished

Function
Integrates Beckhoff Bus Terminal system with DeviceNet

Application
DeviceNet industrial automation bus coupler

Dimension (L*W*H)
Approx. 106 mm x 54 mm x 100 mm

Power Mode
DC powered

Voltage
24 V DC (Supply Voltage)

Power Consumption
Typically 1 W

Accessories
No accessories included

Weight
Approx. 200 g

Communication Protocol
DeviceNet slave

Host Controller Interface
18-pin terminal block

Bus System
DeviceNet

Status Indicators
LEDs for bus status and diagnostics

Device Addressing
Configurable with DIP switches

Network Topology
Supports linear and star DeviceNet topology

Isolation
Galvanic isolation between bus and terminal field

Compatible Series
Beckhoff KL Bus Terminal Series

Fieldbus Connection
DeviceNet bus

Terminal Capacity
Supports up to 64 Bus Terminals

BECKHOFF BK5250 DeviceNet Compact Bus Coupler Trade Information

Minimum Order Quantity
1 Piece

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About BECKHOFF BK5250 DeviceNet Compact Bus Coupler

BECKHOFF BK5250 DeviceNet Compact Bus Coupler

Feature	Specification
I/O Capacity	Supports up to 64 Bus Terminals (extends up to 255 via K-bus extension)
Fieldbus Data Max	512 bytes input and 512 bytes output
Peripheral Signals	Max. 1,020 digital inputs/outputs and 256 analog inputs/outputs
Transmission Rate	Automatic baud rate detection up to 500 kbaud
Bus Interface	1 x 5-pin open pluggable connector (included)
Configuration	Setup via Beckhoff KS2000 software or directly through the controller
Power Supply	24 V DC (-15% / +20%); 11...25 V through DeviceNet bus cable
Current Supply K-Bus	1,750 mA
Status Indicators	2 x Power Supply LEDs, 2 x K-bus LEDs, 2 x Fieldbus LEDs
Physical Dimensions	44 mm x 100 mm x 68 mm (W x H x D) on a 35 mm DIN rail
Approvals	CE, CCC, UL, ATEX, IECEx, cFMus

Effortless DeviceNet Integration

The BK5250 is engineered for easy connection of Beckhoff terminal systems to DeviceNet networks, streamlining communication between fieldbus components. With DIP switch configuration and support for both linear and star topologies, it ensures seamless scalability and adaptability in diverse industrial environments. The compact design and DIN rail mounting allow for efficient cabinet organization, making it an ideal choice for automation projects requiring high connectivity and reliable protocol translation.

Robust Industrial Performance

Industrial automation demands reliability, and the BK5250 meets these requirements with its galvanic isolation, IP20 protection level, and durable plastic housing. Operating efficiently within temperatures from 0C to 55C and up to 95% non-condensing humidity, the coupler withstands challenging factory settings while maintaining system integrity. Diagnostic LEDs provide instant status information, aiding maintenance and minimizing downtime.

FAQ's of BECKHOFF BK5250 DeviceNet Compact Bus Coupler:

Q: How do I configure the device address on the BECKHOFF BK5250 coupler?

A: You can set the device address for the BK5250 using the built-in DIP switches. This allows you to assign a unique address for the DeviceNet network quickly and conveniently.

Q: What is the maximum number of bus terminals supported by the BK5250?

A: The BK5250 DeviceNet Compact Bus Coupler supports up to 64 Beckhoff KL Bus Terminals, providing significant expandability for various automation tasks.

Q: When should the BK5250 be used in an industrial automation setup?

A: Use the BK5250 when you need to integrate Beckhoff KL series terminals with a DeviceNet fieldbus network, especially in distributed I/O systems that require robust protocol translation and compact design.

Q: Where is the BK5250 typically installed within an automation system?

A: The coupler is designed for DIN rail mounting inside a control panel or automation cabinet, together with other fieldbus nodes and power distribution components.

Q: What process is involved in connecting the BK5250 to a DeviceNet network?

A: First, mount the BK5250 on a DIN rail, connect the 24 V DC power supply and DeviceNet bus line, set the device address using the DIP switches, and attach up to 64 KL Bus Terminals. Diagnostic LEDs will help verify correct operation during setup.

Q: How does the BK5250 benefit industrial automation projects?

A: The BK5250 simplifies integration between Beckhoff systems and DeviceNet, offering scalable I/O expansion, reliable diagnostics via LED indicators, and secure communication thanks to galvanic isolation, all of which result in increased system compatibility and operational efficiency.
