OMRON E5EC-RR2ASM-820 48x96 mm Digital Temperature Controller

Send Inquiry

Request To Call Back

OMRON E5EC-RR2ASM-820 48x96 mm Digital Temperature Controller

Name: OMRON E5EC-RR2ASM-820 48x96 mm Digital Temperature Controller
Brand: Industrial Online Services
Price: 15000 INR
Availability: InStock

Price 15000 INR/ Number

Get a Price/Quote

MOQ : 1 Piece

OMRON E5EC-RR2ASM-820 48x96 mm Digital Temperature Controller Specification

Phase
Single Phase

Humidity
25% to 85% RH (Non-condensing)

Output Voltage
Relay, Voltage Pulse (depending on output type)

Protection Level
Front panel: IP66, Rear case: IP20

Mounting Type
Panel Mount

Rated Voltage
100 to 240 VAC

Input Current
10 mA max. (Thermocouple input)

Operating Temperature
-10C to +55C

Frequency
50/60 Hz

Efficiency
High control, PID auto-tuning

Main Material
Flame-resistant Resin (Case); Polycarbonate (Front Panel)

Processing Type
Digital Controller

Condition
New

Function
Temperature Measurement, Control & Display

Application
Industrial Temperature Control, Ovens, Furnaces, Packaging Machines

Dimension (L*W*H)
48 x 96 x 60 mm

Power Mode
AC Powered

Voltage
100 to 240 VAC, 50/60 Hz

Power Consumption
Approx. 8 VA max. (at AC100-240V)

Accessories
User Manual, Mounting Brackets

Communication Interface
RS-485 (Modbus)

Accuracy
0.1% of FS 1 digit

Sampling Period
250 ms

Control Method
PID, ON/OFF

Display Type
Digital 4-digit 7-segment LCD with Status Indicators

Control Output
Relay (2 Outputs), Voltage Pulse

Setpoint Range
-200 to +2300C (Depending on input type)

Weight
Approx. 180 g

Model
E5EC-RR2ASM-820

Sensor Input
Thermocouple, RTD (Pt100)

OMRON E5EC-RR2ASM-820 48x96 mm Digital Temperature Controller Trade Information

Minimum Order Quantity
1 Piece

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About OMRON E5EC-RR2ASM-820 48x96 mm Digital Temperature Controller

The Omron E5EC-RR2ASM-820 is a 48x96 mm digital temperature controller used for precise industrial process and heating regulation.

Key Specifications

Control Outputs: Dual relay outputs (RR) for control output 1 and 2.

Auxiliary Outputs: 2 auxiliary relay outputs.

Power Supply: 100 to 240 VAC.

Input Type: Universal/Full multi-input support (Thermocouples, Pt100 RTD, and analog current/voltage).

Terminal Type: Screw terminals.

Control Modes: ON/OFF or 2-PID with auto-tuning.

Advanced Precision & Versatility

The E5EC-RR2ASM-820 delivers exceptional temperature regulation through high-precision PID auto-tuning and a wide compatibility with both thermocouple and Pt100 RTD sensors. Its versatile design accommodates various industrial needs, ensuring stable and accurate temperature control across multiple environments.

Robust Design & User-Friendly Display

Constructed with flame-resistant materials and featuring a sealed IP66 front panel, this controller offers enhanced durability for industrial settings. The intuitive 4-digit LCD with status indicators provides clear real-time feedback, making operation and monitoring straightforward.

Flexible Connectivity & Control

Equipped with RS-485 Modbus communication, the E5EC easily integrates into automated systems. Its dual relay and voltage pulse outputs support various control strategies, optimally suited for ovens, furnaces, and packaging machinery demanding reliable temperature management.

FAQ's of OMRON E5EC-RR2ASM-820 48x96 mm Digital Temperature Controller:

Q: How do I set up the OMRON E5EC-RR2ASM-820 temperature controller?

A: To set up the E5EC-RR2ASM-820, securely panel-mount it using the mounting brackets provided. Connect the appropriate sensor input (either thermocouple or Pt100 RTD), then wire the relay outputs, power (100-240VAC), and communication lines if needed. Configure control parameters and setpoints through the front LCD interface following the user manual.

Q: What applications is this temperature controller best suited for?

A: This model excels in industrial environments such as ovens, furnaces, and packaging machines. Its precise control methods and robust design enable accurate temperature regulation for process-critical applications across manufacturing, food processing, and other industrial sectors.

Q: When should I use PID control versus ON/OFF control with this device?

A: Use PID control for processes needing precise, stable temperature regulation and minimal overshoot, as in complex manufacturing or sensitive baking processes. ON/OFF control is suitable for less demanding applications where slight temperature variation is acceptable.

Q: Where can the E5EC-RR2ASM-820 be installed safely?

A: Install the controller in environments where ambient temperatures range from -10C to +55C, with humidity between 25% and 85% RH (non-condensing). The IP66-rated front panel ensures protection against dust and water jets, making it suitable for harsh industrial conditions.

Q: What is the process for connecting and configuring sensor inputs?

A: Wire the thermocouple or RTD (Pt100) sensors to the designated terminal blocks at the rear. Select the correct sensor type and configuration through the digital interface, ensuring accurate input recognition and measurement.

Q: How does RS-485 Modbus communication benefit integration?

A: RS-485 (using Modbus protocol) allows seamless integration with automation systems and remote monitoring. This feature is ideal for centralized temperature management, data logging, and streamlined process control in industrial applications.

Q: What are the main benefits of using the E5EC-RR2ASM-820 in industrial temperature control?

A: Key benefits include high precision, fast response time, robust safety features, and user-friendly setup. Its flexibility in sensor input, dual output options, and communication interface support efficient, automated temperature regulation and process consistency.
