SCHNEIDER LXM26DU04M3X High-Performance Motion Servo Drive

Send Inquiry

Request To Call Back

SCHNEIDER LXM26DU04M3X High-Performance Motion Servo Drive

Name: SCHNEIDER LXM26DU04M3X High-Performance Motion Servo Drive
Brand: Industrial Online Services
Price: 25000 INR
Availability: InStock

Price 25000 INR/ Number

Get a Price/Quote

MOQ : 1 Piece

SCHNEIDER LXM26DU04M3X High-Performance Motion Servo Drive Specification

Efficiency
>95%

Output Voltage
Upto 240 VAC (Three Phase)

Rated Voltage
240 V AC

Mounting Type
Panel Mount

Phase
Three Phase

Operating Temperature
0C to +40C

Protection Level
IP20

Input Current
Up to 6 A

Frequency
50/60 Hz

Humidity
5% to 95% non-condensing

Main Material
Metal and high-grade plastic

Processing Type
Servo Drive

Condition
New

Function
High-performance motion servo drive for controlling servo motors

Application
Industrial automation, CNC machines, packaging, robotics

Dimension (L*W*H)
235 x 85 x 210 mm

Power Mode
AC

Voltage
Input: 3 x 200-240 VAC

Power Consumption
Approx. 500 W

Accessories
Standard connectors and terminals included

Cooling Method
Forced Air Cooling

Output Power
4000 W (4 kW)

Short Circuit Protection
Yes

Model Number
LXM26DU04M3X

Communication Interface
CANopen, Modbus, RS232, RS485

Encoder Feedback
Supported (Incremental/Absolute)

Display
LED status indicators

Overvoltage Protection
Yes

Control Method
Vector control, Position/Speed/Torque control

Weight
Approx. 3.2 kg

Storage Temperature
-25C to +65C

About SCHNEIDER LXM26DU04M3X High-Performance Motion Servo Drive

SCHNEIDER LXM26DU04M3X High-Performance Motion Servo Drive

Core Technical Specifications

Power Rating: 400 W (0.4 kW)
Input Voltage: 200V to 230V AC (supports single-phase or three-phase configurations)
Continuous Output Current: 2.6 A at a 16 kHz switching frequency
Line Current: 3 A at 220V
Network Frequency: 47.5 Hz to 63 Hz (50/60 Hz nominal)
Protection Rating: IP20
Interface: Features an integrated front HMI 7-segment display with 5 control buttons.

Applications & Integration

Target Machinery: Ideal for packaging machines, CNC systems, robotics, conveyor controls, and automated assembly setups.
PLC Compatibility: Seamlessly pairs with Schneider Modicon controllers (such as the M221, M241, and M251 series) via EcoStruxure Machine Expert software.
Network Communication: Supports Modbus TCP or EtherCAT networks for smooth standalone or multi-axis configurations.

Advanced Motion Control Precision

The LXM26DU04M3X servo drive empowers industrial systems with accurate position, speed, and torque management. Its vector control technology ensures optimal performance even in the most dynamic applications. This level of control makes it an excellent choice for manufacturers seeking reliability and precision in high-speed automation and robotics operations.

Seamless Communication and Integration

Equipped with support for CANopen, Modbus, RS232, and RS485, this drive easily integrates into a diverse range of automation setups. Standard connectors and terminals are provided for quick installation, while LED status indicators simplify monitoring and fault detection, enhancing efficiency in complex industrial environments.

FAQ's of SCHNEIDER LXM26DU04M3X High-Performance Motion Servo Drive:

Q: How do I install and mount the SCHNEIDER LXM26DU04M3X servo drive?

A: The drive is designed for panel mounting. Secure it within an enclosure ensuring adequate ventilation for forced air cooling. Connect the provided standard connectors and terminals as per the wiring diagram, and verify secure grounding before power-up.

Q: What applications can benefit from using this servo drive?

A: The LXM26DU04M3X excels in industrial automation, CNC machines, packaging equipment, and robotic systems due to its high-speed vector control and multi-mode operation. Its robust features support demanding and precise motion control applications.

Q: When should I use the incremental or absolute encoder feedback options?

A: Incremental encoder feedback is suitable for general speed and position control, while absolute encoders are preferred where precise position tracking after power cycles is critical. Select the encoder type based on your application's accuracy requirement.

Q: Where can I utilize this servo drive in terms of environmental conditions?

A: The drive operates reliably in ambient temperatures from 0C to +40C with humidity levels between 5% and 95% (non-condensing). It is designed with IP20 protection for standard industrial environments and must be installed indoors away from corrosive exposure.

Q: What protections are included to ensure safe operation of the drive?

A: The servo drive features overvoltage and short circuit protection for both user and equipment safety. Status is easily monitored via LED indicators, and forced air cooling mitigates thermal risks during operation.

Q: How does the servo drive enhance process efficiency and productivity?

A: With its high efficiency (>95%), precise control methods, and support for three-phase AC input, the drive reduces energy losses and improves operational consistency. This results in higher productivity, less downtime, and better resource utilization in automated lines.
