SCHNEIDER MPM-UN-CI4-5045 Universal Wireless Network Controller And Gateway Designed For Building Management Systems (BMS), Wireless Control, And Automation

Name: SCHNEIDER MPM-UN-CI4-5045 Universal Wireless Network Controller And Gateway Designed For Building Management Systems (BMS), Wireless Control, And Automation
Brand: Industrial Online Services
Price: 10000 INR
Availability: InStock

Price 10000 INR/ Number

Get a Price/Quote

MOQ : 1 Piece

SCHNEIDER MPM-UN-CI4-5045 Universal Wireless Network Controller And Gateway Designed For Building Management Systems (BMS), Wireless Control, And Automation Specification

Operating Temperature
0C to 50C

Humidity
10% to 90% RH non-condensing

Input Current
Max 150 mA at 24V

Efficiency
High Efficiency Wireless Communication

Frequency
50/60 Hz

Phase
Single Phase

Output Voltage
24V compatible I/O

Mounting Type
DIN Rail or Surface Mount

Rated Voltage
24V AC/DC

Protection Level
IP20

Main Material
High-impact ABS/PC Plastic Enclosure

Processing Type
Wireless Network Controller & Gateway

Condition
New

Function
Universal Wireless Network Controller and Gateway for BMS

Application
Building Management System, Wireless Control, Automation, Smart Buildings

Dimension (L*W*H)
120 mm x 110 mm x 38 mm

Power Mode
Mains Power

Voltage
24V AC/DC

Power Consumption
<3 W typical

Battery Life
Not Applicable (Mains Powered)

Accessories
User Manual, Mounting Screws

Weight
320 g

I/O Points
4 Universal Inputs, 4 Digital Outputs

Wireless Frequency
2.4 GHz ISM Band (for ZigBee/EnOcean)

Communication Ports
RS485, Ethernet, USB

Protocols Supported
BACnet, Modbus, ZigBee, EnOcean

Panel Indicator
LED Status Indicators

Color
Grey

Installation Environment
Indoor Use Only

Product Type
Universal Wireless Network Controller and Automation Gateway

Storage Temperature
-20C to 70C

Data Rate
Up to 100 kbps wireless data rate

Firmware Upgrade
USB via PC or Over-the-air Supported

Network Security
128-bit AES Encryption

Model Number
MPM-UN-CI4-5045

SCHNEIDER MPM-UN-CI4-5045 Universal Wireless Network Controller And Gateway Designed For Building Management Systems (BMS), Wireless Control, And Automation Trade Information

Minimum Order Quantity
1 Piece

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About SCHNEIDER MPM-UN-CI4-5045 Universal Wireless Network Controller And Gateway Designed For Building Management Systems (BMS), Wireless Control, And Automation

SCHNEIDER MPMUNCI45045 Universal Wireless Network Controller And Gateway Designed For Building Management Systems BMS Wireless Control And Automation

Key Technical Specifications

Wireless Protocols EnOcean 315 MHz and ZigBee Pro

Wired Communication Modbus

InputOutput 6 IO channels

Power Supply 24V DC

Ecosystem Compatibility Integrated within EcoStruxure Building Expert lines

Effortless BMS Integration

Designed as a universal gateway, the MPM-UN-CI4-5045 connects and manages multiple wireless and wired field devices, bridging diverse protocols like BACnet, Modbus, ZigBee, and EnOcean within building management systems. With support for both RS485 and Ethernet communication, it offers flexible system architectures and is ideal for enhancing automation across modern, smart facilities.

Reliable Wireless Performance

Operating on the 2.4 GHz ISM band, this controller achieves efficient wireless connectivity with up to 100 kbps data rate, ensuring timely and accurate data transmission. Its high standard for information security is assured by 128-bit AES encryption, while over-the-air (OTA) firmware updates keep network capabilities current and reliable without physical intervention.

FAQ's of SCHNEIDER MPM-UN-CI4-5045 Universal Wireless Network Controller And Gateway Designed For Building Management Systems (BMS), Wireless Control, And Automation:

Q: How do I install the SCHNEIDER MPM-UN-CI4-5045 Universal Wireless Network Controller?

A: The unit can be mounted on a DIN rail or flat surface using the included mounting screws. Ensure it is installed indoors in an area with humidity between 10% and 90% RH and temperatures from 0C to 50C. Simply connect the 24V AC/DC power and required communication ports (RS485, Ethernet, USB) according to the user manual.

Q: What protocols does this network controller support for integration with different BMS components?

A: The MPM-UN-CI4-5045 supports BACnet, Modbus, ZigBee, and EnOcean protocols, allowing for integration with a wide range of building management devices for wireless control and automation.

Q: When should firmware on the controller be updated, and what is the process?

A: Firmware should be updated when enhancements or security updates are released by Schneider. Updates can be performed via USB from a PC or wirelessly (over-the-air), ensuring uninterrupted operation and access to new features.

Q: Where should the controller be installed for optimal performance?

A: This device is designed strictly for indoor installation in non-condensing environments. Place it within a central location to maximize wireless coverage and near compatible network infrastructure for efficient connectivity.

Q: What are the main benefits of using the MPM-UN-CI4-5045 in a building automation scenario?

A: It enables seamless integration of both wired and wireless devices, enhances interoperability between multiple protocols, and increases security with 128-bit AES encryption. Its OTA upgrade capability and LED indicators further simplify maintenance and monitoring.

Q: How do I use the I/O points on the controller?

A: The device features four universal inputs for connecting various sensors and four digital outputs to control different actuators. These can be managed via the controller's onboard configuration interface, supporting diverse automation processes in BMS.
