ALLEN BRADLEY 1746-IB16 16-Point DC Digital Input Module

Name: ALLEN BRADLEY 1746-IB16 16-Point DC Digital Input Module
Brand: Industrial Online Services
Price: 15000 INR
Availability: InStock

Price 15000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

ALLEN BRADLEY 1746-IB16 16-Point DC Digital Input Module Specification

Model No
1746-IB16

Chip Type
Digital Input Processor

I/O Cards Type
Input Module

Condition
Used

Compatible Port/Slot
SLC 500 Rack Slot

Use
Industrial Automation, PLC Input Module

Status Indicators
LED per input

Number of Inputs
16

Isolation Voltage
500V AC

Operating Temperature
0 to 60C

Module Width
1 slot

Connection Type
Removable Terminal Block

Weight
Approx. 0.3 kg

Input Current
8 mA at 24V DC

Mounting
Rack Mountable - SLC 500 Series

Storage Temperature
-40 to 85C

Dimension
Approx. 150mm x 130mm x 40mm

Input Voltage Range
10-30V DC

Module Type
DC Digital Input

ALLEN BRADLEY 1746-IB16 16-Point DC Digital Input Module Trade Information

Minimum Order Quantity
1 Piece

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About ALLEN BRADLEY 1746-IB16 16-Point DC Digital Input Module

ALLEN BRADLEY 1746-IB16 16-Point DC Digital Input Module

Core Specifications

Inputs: 16 sinking DC inputs configured across 1 single common group.
Operating Voltage Range: 10 to 30V DC (Nominal 24V DC).
Backplane Current Consumption: 50 mA (or up to 85 mA depending on series version) at 5V DC; 0 mA at 24V DC.
Signal Delay: Maximum of 8 ms for both ON and OFF state transitions.
Maximum Off-State Current / Voltage: 1 mA / 5.0V DC.
Isolation: 500V DC electrical isolation between communication circuits.
Hardware Features: Includes a removable terminal block for simplified wiring and front-facing LED status indicators for each channel.

Advanced Input Monitoring for Industrial Automation

The 1746-IB16 delivers precise and dependable input monitoring for SLC 500 PLC systems. Featuring 16 discrete DC inputs, the module is optimized for performance in a broad range of industrial settings. Its compact size helps save rack space, while LED status indicators for each channel promote efficient troubleshooting and maintenance.

Versatile and Easy Installation

Engineered for quick integration, the 1746-IB16 features a removable terminal block and occupies only one slot in the SLC 500 rack. The rack-mountable design streamlines setup in control panels, and the module's operating temperature range ensures reliability in challenging plant floor environments.

FAQ's of ALLEN BRADLEY 1746-IB16 16-Point DC Digital Input Module:

Q: How do I install the ALLEN BRADLEY 1746-IB16 input module in my SLC 500 system?

A: Installation involves snapping the module into a vacant slot on your SLC 500 rack, then wiring field devices to the removable terminal block. Ensure the system is powered off before connecting the module, and firmly secure all wiring according to the manufacturer's instructions.

Q: What are the primary uses of the 1746-IB16 input module?

A: This module is primarily used to receive digital signals from field devices such as sensors or switches. It is ideal for industrial automation applications where reliable monitoring of DC inputs is needed, such as manufacturing process control and equipment status tracking.

Q: What benefit do LED status indicators provide on this module?

A: The individual LED indicators give real-time visual feedback for each input channel, making it easy to diagnose wiring faults or device failures and reducing system troubleshooting time during regular operation or maintenance.

Q: Where can the 1746-IB16 be used considering its temperature range?

A: With an operating temperature of 0C to 60C and storage range from -40C to 85C, the module is suitable for most indoor industrial environments, including factory floors, automation panels, and process control rooms.

Q: What is the input voltage and current specification for each channel?

A: Each input channel on the 1746-IB16 can accept DC signals between 10 to 30V, with a typical input current of 8 mA at 24V DC, ensuring compatibility with a variety of field devices.

Q: How is electrical isolation achieved in the 1746-IB16 module?

A: The module offers 500V AC isolation between field wiring and backplane circuitry, which helps protect the controller and enhance system safety in electrically noisy environments.

Q: What is the process for replacing or servicing the module?

A: First, power down the PLC system. Then, disconnect field wiring from the removable terminal block, release the module from the rack slot, and replace or service as needed. Refer to the user manual for detailed guidance to avoid damage or unsafe conditions.
