ALLEN BRADLEY 1763-L16BBB Compact MicroLogix 1100 Programmable Logic Controller

Name: ALLEN BRADLEY 1763-L16BBB Compact MicroLogix 1100 Programmable Logic Controller
Brand: Industrial Online Services
Price: 25000 INR
Availability: InStock

Price 25000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

ALLEN BRADLEY 1763-L16BBB Compact MicroLogix 1100 Programmable Logic Controller Specification

Model No
1763-L16BBB

Chip Type
Microprocessor Based

I/O Cards Type
Digital Inputs/Outputs, Analog Inputs

Condition
Used / Refurbished

Compatible Port/Slot
Ethernet Port, RS-232 (D-Sub 9) Port, Expansion Slot

Use
Industrial Automation

OS Supported
Compatible with RSLogix 500

Dimensions
90 mm x 110 mm x 87 mm (HxWxD) approx.

Expansion Capability
Supports additional I/O modules

Operating Temperature
0C to 55C

Programming Software
RSLogix 500

Number of Outputs
6 Relay Outputs

Number of Inputs
10 Digital, 2 Analog

Communication Ports
Ethernet, RS-232/RS-485 Combo Port

Mounting Type
DIN Rail or Panel Mount

Series
MicroLogix 1100

Display Type
LCD (Backlit) with Navigation Buttons

Input Voltage
24V DC

Application
Industrial Control, Automation Processes, Machine Control

Memory
10 KB User Memory

Weight
Approx. 0.4 kg

Realtime Clock
Integrated

ALLEN BRADLEY 1763-L16BBB Compact MicroLogix 1100 Programmable Logic Controller Trade Information

Minimum Order Quantity
1 Piece

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About ALLEN BRADLEY 1763-L16BBB Compact MicroLogix 1100 Programmable Logic Controller

Allen-Bradley 1763-L16BBB is a discontinued MicroLogix 1100 Programmable Logic Controller (PLC) featuring 10 digital inputs, 2 analog inputs, and 6 digital outputs.

Key Technical Specifications

Power Supply: 24V DC
Digital Inputs: 10 channels (24V DC)
- Includes 4 high-speed inputs for fast-counting applications
Analog Inputs: 2 channels (0-10V DC) with 10-bit resolution
Digital Outputs: 6 channels in total

2 Relay outputs
4 FET (transistor) outputs (24V DC)
Memory Capacity: 8 KB total memory split into:
- 4 KB user program memory
- 4 KB user data memory
Data Logging: Supports up to 128 KB maximum.
Recipe Storage: Supports up to 64 KB maximum (shares space with data logging memory)

Connectivity & Features
- Dual Communication Ports: Built-in isolated RS-232/RS-485 combo port and one 10/100 Mbps Ethernet/IP port.
- Integrated LCD: Front-facing display for checking I/O status, modifying controller settings, and monitoring system messages.
- Programming Software: Programmed using RSLogix 500 or RSLogix Micro software.
- Online Editing: Allows you to modify logic code on-the-fly without shutting down the controller.
- Form Factor: Compact design (90 x 110 x 87 mm) suitable for standard DIN Rail or panel mounting

Highly Adaptable Industrial Control

The 1763-L16BBB MicroLogix 1100 PLC is engineered for flexible use in automation processes. Suitable for machine control and general-purpose industrial applications, its expandable design fits evolving I/O requirements. Its Ethernet and serial communication options enable compatibility with existing industrial networks and remote monitoring, enhancing integration and control efficiency.

User-Friendly Operation and Programming

This PLC features a bright LCD display and convenient navigation buttons for swift local interaction and diagnostics. Programming is streamlined with RSLogix 500 software, which is widely used across industries. The simple integration of expansion modules makes this controller an efficient choice for both routine and advanced automation tasks.
