SCHNEIDER HMIS85 5.7-Inch Small Touchscreen Display Front Module Belonging To The Harmony SCU Series

Send Inquiry

Request To Call Back

SCHNEIDER HMIS85 5.7-Inch Small Touchscreen Display Front Module Belonging To The Harmony SCU Series

Name: SCHNEIDER HMIS85 5.7-Inch Small Touchscreen Display Front Module Belonging To The Harmony SCU Series
Brand: Industrial Online Services
Price: 15000 INR
Availability: InStock

Price 15000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

SCHNEIDER HMIS85 5.7-Inch Small Touchscreen Display Front Module Belonging To The Harmony SCU Series Specification

Rated Voltage
24V DC

Input Current
Max 0.22 A

Mounting Type
Panel Mount

Humidity
10% to 90% non-condensing

Efficiency
High display and operation efficiency

Operating Temperature
0C to +50C

Protection Level
IP66 (front panel), IP20 (rear)

Phase
Single Phase

Frequency
50/60 Hz (for ancillary devices)

Main Material
Plastic, Glass

Processing Type
Electronic Touchscreen

Condition
New

Function
Front touchscreen display for Harmony SCU, graphical operator interface

Application
Industrial Automation, HMI (Human Machine Interface), Control Panels

Dimension (L*W*H)
166 x 135 x 30 mm

Power Mode
External DC Power Supply

Voltage
24V DC

Power Consumption
4 W

Accessories
No additional accessories included

Backlight Type
LED

Approvals/Certifications
CE, UL, CSA, C-Tick

Touchscreen Type
Resistive

Interface
USB (for programming), Serial Ports

Display Type
TFT LCD with touchscreen

Model Number
HMIS85

Storage Temperature
-20C to +60C

Display Size
5.7 inches

Color
Black

Front Panel Material
Polycarbonate

Product Series
Harmony SCU

Weight
Approx. 0.5 kg

Display Resolution
320 x 240 pixels (QVGA)

SCHNEIDER HMIS85 5.7-Inch Small Touchscreen Display Front Module Belonging To The Harmony SCU Series Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About SCHNEIDER HMIS85 5.7-Inch Small Touchscreen Display Front Module Belonging To The Harmony SCU Series

SCHNEIDER HMIS85 5.7-Inch Small Touchscreen Display Front Module Belonging To The Harmony SCU Series

Key Specifications

Display Details: Features a 5.7-inch backlit LED colour TFT LCD screen with a 320 x 240 pixel (QVGA) resolution supporting up to 65,536 colours.
Touch Panel: Built with an analogue resistive touch panel featuring 16 brightness adjustment levels configured directly via the interface.
Lifespan & Reliability: The integrated LED backlight delivers a lifespan of up to 50,000 hours.
Connectivity: Supports robust industrial communication including Ethernet (RJ45), USB Type-A, and serial transmission.
Input Voltage: Runs on standard industrial 24V DC power supply with a low power consumption of approximately 1.6 W.
Language Support: Native configuration support for ASCII, Simplified Chinese, Traditional Chinese, Japanese (ANK, Kanji) and Korean fonts.

Reliable Touchscreen Display for Industrial Automation

The Harmony SCU HMIS85 touchscreen module offers dependable operator control and process monitoring in industrial automation environments. Its 5.7-inch TFT LCD panel features a resistive touch interface for precise local input, while LED backlighting ensures visibility in varied lighting. Engineered for panel mounting, the HMIS85 is designed to withstand rigorous conditions, boasting IP66 front protection and support for wide temperature and humidity ranges, making it a trustworthy solution for control panels.

Efficient Integration and Versatile Connectivity

Designed with ease of integration in mind, the HMIS85 provides USB and serial ports for swift programming and communication with other devices. Its compact dimensions and lightweight design facilitate straightforward installation, while support for key industrial standards and certification allows for deployment in diverse settings. The front panel's polycarbonate construction enhances durability and longevity, ensuring reliable operation across demanding applications.

FAQ's of SCHNEIDER HMIS85 5.7-Inch Small Touchscreen Display Front Module Belonging To The Harmony SCU Series:

Q: How do I mount the SCHNEIDER HMIS85 touchscreen module in my industrial control panel?

A: The HMIS85 is designed for panel mounting, fitting into cut-outs with its compact dimensions (166 x 135 x 30 mm). Secure installation ensures the IP66-rated front panel is exposed for optimal dust and water protection, while the rest of the unit remains protected inside the enclosure.

Q: What are the main advantages of using the HMIS85 in industrial automation?

A: This module delivers high operational efficiency with clear graphical displays, reliable resistive touch input, and robust environmental protection (IP66 front, wide temperature range). Its certifications (CE, UL, CSA, C-Tick) ensure safety and compliance for industrial automation and control panels.

Q: When is the HMIS85 most suitable?

A: It is most suitable for new installations or upgrades in industrial automation systems requiring a compact, durable, and efficient HMI for process control, system monitoring, or machine interface applications.

Q: Where can the HMIS85 be used within industrial environments?

A: The HMIS85 can be integrated into control panels, operator stations, or any industrial equipment requiring a human-machine interface. Its high protection rating and robust design make it effective in manufacturing facilities, assembly lines, and other harsh environments.

Q: What connectivity options are available on the HMIS85 panel?

A: The HMIS85 supports USB programming and includes serial ports for direct communication with compatible controllers and devices, facilitating flexible integration into various industrial automation architectures.

Q: How is the HMIS85 powered and what is its energy consumption?

A: The unit operates on a 24V DC external power supply, consuming a maximum of 4 watts and drawing up to 0.22 A, making it energy-efficient for continuous industrial use.
