SCHNEIDER TM2AMI4LT 4-Channel Analog Input Module Designed For Industrial Automation And Logic Expansion

Name: SCHNEIDER TM2AMI4LT 4-Channel Analog Input Module Designed For Industrial Automation And Logic Expansion
Brand: Industrial Online Services
Price: 15000 INR
Availability: InStock

Price 15000 INR/ Number

Get a Price/Quote

MOQ : 1 Piece

SCHNEIDER TM2AMI4LT 4-Channel Analog Input Module Designed For Industrial Automation And Logic Expansion Specification

Phase
Single Phase

Efficiency
High accuracy analog input processing

Protection Level
IP20

Operating Temperature
-20C to +60C

Rated Voltage
24V DC

Humidity
5% to 95% non-condensing

Input Current
Max 40 mA

Mounting Type
DIN Rail Mount

Frequency
50/60 Hz

Main Material
ABS Plastic, Metal Components

Processing Type
Electronic Automation Module

Condition
New

Function
Analog Input Module - signal acquisition

Application
Industrial Automation, Logic Expansion, PLC

Dimension (L*W*H)
110 mm x 32 mm x 70 mm

Power Mode
External Power Supply

Voltage
24V DC

Power Consumption
Less than 2W

Accessories
Terminal connectors included

Storage Temperature
-25C to +70C

Resolution
12 bit

Weight
Approx. 200 grams

Isolation
Optical Isolation between channels

Number of Channels
4 Channels

Input Range
0-10V, 0-20mA, 4-20mA

Response Time
<1ms

Compatibility
EcoStruxure, Modicon M221/M241/M251

Connector Type
Removable Terminal Block

Input Type
Analog (Voltage, Current)

Model
TM2AMI4LT

Communication Protocol
Compatible with Modicon Logic Controllers

SCHNEIDER TM2AMI4LT 4-Channel Analog Input Module Designed For Industrial Automation And Logic Expansion Trade Information

Minimum Order Quantity
1 Piece

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About SCHNEIDER TM2AMI4LT 4-Channel Analog Input Module Designed For Industrial Automation And Logic Expansion

SCHNEIDER TM2AMI4LT 4Channel Analog Input Module Designed For Industrial Automation And Logic Expansion

Key Specifications

Inputs 4 nondifferential analog channels

Signal Types Supports Voltage 010V Current 020mA 420mA and Temperature Probes Pt100 Pt1000 Ni100 Ni1000

Resolution 12 bits

Power Supply Rated at 24V DC limits of 204 to 288V

Form Factor Compact size 235 x 70 x 90 mm with a 35mm DIN rail mounting mechanism and a removable screw terminal block

Compatibility Integrates with Modicon M238 Twido and Advantys OTB logic controllers

High-Precision Analog Signal Input

The TM2AMI4LT module offers four independent analog input channels with a 12-bit resolution, enabling accurate acquisition of voltage or current signals for detailed process monitoring and control. Its response time of less than 1 millisecond ensures real-time data availability for critical industrial operations.

Seamless Integration and Versatility

Engineered for compatibility with Modicon M221, M241, and M251 logic controllers, the module supports easy installation with a removable terminal block and reliable DIN rail mounting. It integrates flawlessly within EcoStruxure-enabled automation systems, making it ideal for scalable industrial logic expansion.

FAQ's of SCHNEIDER TM2AMI4LT 4-Channel Analog Input Module Designed For Industrial Automation And Logic Expansion:

Q: How do I install the SCHNEIDER TM2AMI4LT analog input module in my control panel?

A: To install the TM2AMI4LT module, simply mount it on a standard DIN rail and connect the removable terminal blocks to your analog input sources. Ensure the module is powered with an external 24V DC supply and follow the wiring diagram provided in the user manual for optimal configuration.

Q: What types of analog signals does the TM2AMI4LT support, and what is its input range?

A: This module supports both voltage (0-10V) and current (0-20mA, 4-20mA) input types. It is designed to handle a wide range of analog sensors and transducers commonly used in industrial automation for process monitoring.

Q: When should I use optical isolation in an analog input module?

A: Optical isolation, as featured in the TM2AMI4LT, should be used when you need to prevent electrical interference or ground loop issues between channels and the central controller, ensuring safe and accurate signal processing in electrically noisy environments.

Q: Where can the TM2AMI4LT be used within an industrial environment?

A: This module is intended for use in industrial automation control panels, PLC-based machinery, and processing plants, especially where enhanced logic expansion and reliable signal acquisition are required.

Q: What is the process for connecting the module to Modicon logic controllers?

A: Connect the TM2AMI4LT to your Modicon M221, M241, or M251 controller via the designated expansion port. Configure the module settings in your programming software (such as EcoStruxure Machine Expert), map the required input channels, and assign signal parameters as needed.

Q: How does using the TM2AMI4LT benefit my automation system?

A: By utilizing the TM2AMI4LT, you gain high-accuracy analog data input, fast response times, and improved signal reliability, leading to enhanced process control and more efficient automation performance. Its compatibility with Schneider's platforms further streamlines system integration.
