ALLEN BRADLEY 1746-ITB16 16-Point Fast-Response Digital Input Module

Send Inquiry

Request To Call Back

ALLEN BRADLEY 1746-ITB16 16-Point Fast-Response Digital Input Module

Name: ALLEN BRADLEY 1746-ITB16 16-Point Fast-Response Digital Input Module
Brand: Industrial Online Services
Price: 10000 INR
Availability: InStock

Price 10000 INR/ Number

Get a Price/Quote

MOQ : 1 Piece

ALLEN BRADLEY 1746-ITB16 16-Point Fast-Response Digital Input Module Specification

Chip Type
Digital Input Module

Model No
1746-ITB16

I/O Cards Type
Fast-Response Digital Input

Condition
Used/Refurbished

Compatible Port/Slot
SLC 500 Series Slot

Use
PLC Input Expansion

OS Supported
Allen Bradley PLC Operating System

Weight
Approx. 0.75 kg

Input Voltage Range
24V DC

Response Time
1 ms

Dimensions
Approx. 151 x 35 x 143 mm

Series
SLC 500

Input Points
16

Backplane Current
0.2A @ 5V DC

Module Type
High-Speed Digital Input

Mounting
Rack Mount (SLC 500 Chassis)

Application
Industrial Automation, High-Speed Sensing

LED Indicators
Status for each input

Terminal Type
Removable Screw Terminal Block

Part Number
1746-ITB16

Isolation
500V AC (Tested between inputs and logic)

Operating Temperature
0C to 60C

ALLEN BRADLEY 1746-ITB16 16-Point Fast-Response Digital Input Module Trade Information

Minimum Order Quantity
1 Piece

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About ALLEN BRADLEY 1746-ITB16 16-Point Fast-Response Digital Input Module

ALLEN BRADLEY 1746-ITB16 16-Point Fast-Response Digital Input Module

Key Technical Specifications

Input Configuration: 16 channels, Sinking (NPN) wiring format, with 16 points per common.
Operating Voltage: 10 to 30V DC range, with a nominal operational voltage of 24V DC.
Current Draw: 0.085 A (85 mA) backplane power consumption at 5V DC.
Isolation: 500V DC communication circuits isolation.
Termination: Uses a standard removable 18-point terminal block.

High-Speed Input Expansion for SLC 500 Systems

Achieve rapid input data collection with the ALLEN BRADLEY 1746-ITB16. This module supports 16 digital inputs operating at 24V DC, with a notable response time of just 1 ms. Its robust design and compatibility with SLC 500 chassis allow seamless integration, ensuring your system responds swiftly in demanding automation environments.

Durable Design with Enhanced Safety Features

Built to endure industrial settings, the 1746-ITB16 includes 500V AC isolation between logic and inputs, safeguarding your system's components. The removable screw terminal block enables quick and reliable wiring, while the sturdy rack-mount structure holds up in tough conditions. LED indicators for each input provide immediate diagnostic feedback.

FAQ's of ALLEN BRADLEY 1746-ITB16 16-Point Fast-Response Digital Input Module:

Q: How do I install the ALLEN BRADLEY 1746-ITB16 module in my SLC 500 chassis?

A: To install the 1746-ITB16, power down the SLC 500 PLC, insert the module into an available I/O slot, secure it using the mounting hardware, and connect your input wiring to the removable screw terminal block. Reapply power and verify input status using the LED indicators.

Q: What applications benefit from using the 1746-ITB16 fast-response digital input module?

A: This module is ideal for high-speed industrial automation tasks such as machine control, process monitoring, and rapid event sensing where quick detection of digital signals at 1 ms response time is required.

Q: When is it necessary to choose a fast-response digital input module like the 1746-ITB16?

A: Select this module when your automation process requires immediate recognition of input signals, such as in packaging lines, safety interlocks, or real-time counting applications where delayed detection could impact efficiency.

Q: Where should the ALLEN BRADLEY 1746-ITB16 be mounted within a PLC system?

A: The module is designed for rack mounting in a compatible Allen Bradley SLC 500 series chassis, occupying a standard I/O slot for seamless integration with existing PLC setups.

Q: What is the process for wiring external devices to the module's input points?

A: Connect your 24V DC devices to the corresponding input terminals on the removable screw terminal block, ensuring connections are secure and match the wiring diagram for your application. Each input is optically isolated for safety.

Q: How do the LED indicators on the 1746-ITB16 assist in troubleshooting?

A: Each input has a dedicated LED indicator that lights up when the corresponding input is active, allowing for quick visual confirmation of operation and helping to diagnose wiring or signal issues efficiently.
