IDEC FC4A-PM64 64 KB EEPROM Memory Cartridge

Name: IDEC FC4A-PM64 64 KB EEPROM Memory Cartridge
Brand: Industrial Online Services
Price: 5000 INR
Availability: InStock

Price 5000 INR/ Number

Get a Price/Quote

MOQ : 1 Piece

IDEC FC4A-PM64 64 KB EEPROM Memory Cartridge Specification

Protection Level
Standard dust protection

Operating Temperature
0C to 55C (standard IDEC environmental rating)

Mounting Type
Plug-in/Insert module

Humidity
10% to 95% RH (non-condensing, typical for IDEC PLC accessories)

Main Material
Plastic housing, electronic components

Processing Type
EEPROM Data Storage

Condition
New

Function
64KB EEPROM Memory Cartridge for data backup and program storage

Application
Memory expansion for IDEC programmable logic controllers (PLCs)

Dimension (L*W*H)
Compact cartridge, approx. 30 mm x 25 mm x 7 mm (estimation)

Accessories
None included

Model Number
FC4A-PM64

Memory Type
EEPROM

Product Category
PLC Memory Cartridge

Weight
Approx. 10 grams

Installation
Direct cartridge slot on controller

Compatible Devices
IDEC MicroSmart Pentra PLC series

Memory Size
64 KB

Color
Beige/White

IDEC FC4A-PM64 64 KB EEPROM Memory Cartridge Trade Information

Minimum Order Quantity
1 Piece

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About IDEC FC4A-PM64 64 KB EEPROM Memory Cartridge

The IDEC FC4A-PM64 is a 64 KB EEPROM memory cartridge designed for the IDEC MicroSmart Series of Programmable Logic Controllers

Technical Specifications

Memory Capacity: 64 KB, which expands the PLC's user program capacity up to 64,500 bytes or roughly 10,750 steps.
Memory Type: Non-volatile EEPROM.
Lifecycle Status: Discontinued by manufacturer.

Compatibility Requirements

PLC Hardware: Specifically compatible with Slim-type MicroSmart CPU modules, including models FC4A-D20RK1, FC4A-D20RS1, FC4A-D40K3, and FC4A-D40S3.
Firmware: Requires the CPU module to have system program version 2.01 or higher.
Software: To write or edit user programs that exceed 32 KB (5,200 steps), you must use WindLDR programming software version 4.2 or higher.

Plug-and-Play Memory Expansion

The IDEC FC4A-PM64 memory cartridge allows for quick and effortless expansion of your PLC system's memory. Simply insert it into the dedicated slot on the MicroSmart Pentra PLC series controller to enhance data storage and backup capabilities, without complicated setup or configuration.

Reliable Data Backup and Storage

Featuring a 64 KB EEPROM for non-volatile data storage, the FC4A-PM64 ensures your system programs and essential operational data are safely preserved even when power is lost. This is critical in maintaining system integrity during maintenance or unexpected shutdowns.

Built for Industrial Environments

With an operating temperature range of 0C to 55C and 10% to 95% humidity tolerance, this cartridge endures typical workplace conditions. Its durable plastic housing and standard dust protection make it a dependable accessory for PLC expansion needs.

FAQ's of IDEC FC4A-PM64 64 KB EEPROM Memory Cartridge:

Q: How do I install the IDEC FC4A-PM64 memory cartridge?

A: To install the FC4A-PM64, simply insert the cartridge into the designated memory slot found on the IDEC MicroSmart Pentra PLC controller. No additional tools or accessories are required for installation.

Q: What are the benefits of adding a 64 KB EEPROM memory cartridge to my PLC system?

A: The added cartridge allows for increased storage of controller programs and critical data, ensuring secure backup and facilitating smoother upgrades or maintenance, ultimately improving system reliability and efficiency.

Q: When should I use the FC4A-PM64 memory cartridge in my automation setup?

A: Use the FC4A-PM64 whenever you require additional non-volatile storage for your PLC, especially if your application involves large or complex programs, frequent updates, or the need for secure data backup.

Q: Where can the IDEC FC4A-PM64 memory cartridge be used?

A: This cartridge is designed specifically for use with IDEC MicroSmart Pentra PLC series controllers, commonly found in industrial automation, process control, and manufacturing environments.

Q: What kind of devices is the FC4A-PM64 compatible with?

A: The FC4A-PM64 is compatible exclusively with IDEC MicroSmart Pentra series programmable logic controllers (PLCs), serving as a dedicated memory expansion accessory.

Q: What process should I follow for data backup using the FC4A-PM64?

A: After the cartridge is installed, use the PLC's built-in backup and restore features to write programs and data to the EEPROM cartridge, ensuring continuous protection and easy recovery.

Q: What usage conditions does the FC4A-PM64 support?

A: This cartridge operates within a temperature range of 0C to 55C and in humidities from 10% to 95% RH (non-condensing), aligning with standard IDEC PLC environmental specifications.
